Disc & Drum: Specifications Kia Spectra I рестайлинг

SPECIFICATION

Verify that distance from the center of the pedal to the engine compartment bulkhead is as specified.

Specification: 7.60-7.72 in (193-196 mm)

Scheme 1

1. Disconnect brake pedal switch connector.
2. Loosen locknut B and rotate switch A until it does not contact pedal.
3. Loosen locknut D and turn rod C to adjust height of the brake pedal. If necessary, further rotate switch A to prevent it from contacting pedal.
4. Rotate brake pedal switch A in until plunger is completely compressed, then rotate it out about 1/2 turn. Tighten locknuts B and D.
5. Reconnect brake pedal switch connector.
6. Verify operation of stoplights.

Scheme 2

1. Pump pedal a few times (with engine off) to eliminate any slack in system.
2. To measure pedal free play, gently press pedal by hand until resistance is felt. Pedal free play: 0.16-0.28 in (4-7 mm)

Scheme 3

1. Loosen locknut D and turn rod C to adjust free play.
2. Verify pedal height and stoplight operation.
3. Tighten locknut D.

Scheme 4

1. Verify that clearance from floor to center of the pedal pad is as specified when pedal is pressed with a force of about 132 lb (65 Kg). Pedal-to-floor clearance: Minimum: 2.75 in (70.0 mm)
2. If clearance is less than required, check for the following. Air in brake system. Malfunctioning automatic adjuster (rear brake drums).
