Button Engine Start System: Removal & Installation Kia Soul I рестайлинг

Installation

1. Install the start/stop button.
2. Install the crash pad lower panel.

Scheme 110

Scheme 111

Scheme 112

Scheme 113

1. Disconnect the negative(-) battery terminal.
2. Remove the glove box and disconnect the FOB holder connector(A).
3. Loosen 3 screws.
4. Remove the FOB holder(A) from the glove box.

Scheme 114

1. Install the FOB holder to the glove box.
2. Install the glove box to the crash pad.
3. Connect the negative(-) battery terminal.

Scheme 115

Scheme 116

Scheme 117

Scheme 118

Scheme 119

1. Disconnect the negative(-) battery terminal.
2. Remove the crash pad. (Refer to the " «CRASH PAD»(ref-537227-S36224571332013032200000) ")
3. Remove the PDM relay(A).
4. Disconnect the PDM connector. Remove the PDM(A) after loosening a bolt and nut.

1. Install the PDM and the PDM relay. Connect the PDM connector.
2. Install the crash pad.
3. Connect the negative(-) battery terminal.
