Manual Transaxle Control System - 2.0L: Specifications Kia Soul I рестайлинг

Specifications

BACK-UP LAMP SWITCH SPECIFICATION

Scheme 73

Scheme 74

1. Disconnect the back up lamp switch connector (A).
2. Check the continuity between no. 1 and 2 terminals of backup lamp switch. When the shift lever is in reverse, there should be continuity.
3. If necessary, repair or replace the backup lamp switch.

Scheme 75

Scheme 76

1. Disconnect the back up lamp switch connector (A).
2. Remove the back up lamp switch (A).
3. Replace a new one and install the back up lamp switch. Tightening torque: 29.4 ~ 34.3 N.m (3.0 ~ 3.5 kgf.m, 21.7 ~ 25.3 lb-ft)
