Audio System: Specifications Kia Soul I рестайлинг

Entertainment Systems 2 illustrations

Terminal specification (PA710S)

Pin NOCommentsRemarksOutput voltage (V)
A1Loudspeaker Rear Left+Needed connection to the carAnalog output
A2Loudspeaker Front Left+Needed connection to the carAnalog output
A3Loudspeaker Front Right+Needed connection to the carAnalog output
A4Loudspeaker Rear Right+Needed connection to the carAnalog output
A8Rheostat from vehicle +
A10Loudspeaker Rear LeftNeeded connection to the carAnalog output
A11Loudspeaker Front LeftNeeded connection to the carAnalog output
A12Loudspeaker Front RightNeeded connection to the carAnalog output
A13Loudspeaker Rear RightNeeded connection to the carAnalog output
A17Rheostat from vehicle
A18Remote supply for motorized antennaACC on9V ~ 18V
B4Steering Wheel Remote ControlSteering Wheel switch pushed0.5V ~ 3V
B6USB D+USB device is inserted3.2V ~ 3.45
B7USB/iPod powerUSB/iPod device is inserted4.9V ~ 5.1V
B8AUX Right Sound SignalExternal Auxiliary device is Audio playing (At time of Aux jack use)A waveform synchronized with sound is output
B9AUX Reference GroundAlwaysBelow 1 ohm
B10Bluetooth MIC+Input the Voice Signal via MICA waveform synchronized with Voice data via MIC
B11AccessoryEngine switch on(ACC)11 ~ 14 V
B12BatteryAlways11 ~ 14 V
B16Speed Sensor SignalEngine switch on(IGN), car is moved slowlyApprox. 5V Level Pulse Generation
B17Steering Wheel Remote Control GndAlwaysBelow 1 ohm
B18USB data lineUSB device is inserted3.2V ~ 3.45
B19IPod detection lineIPod device is insertedGND
B20AUX Signal Input DetectAuxiliary device is inserted0V(Low) --> 5V(High)
B21AUX Left Sound SignalExternal Auxiliary device is Audio playing (At time of Aux jack use)A waveform synchronized with sound is output
B22Bluetooth MICInput the Voice Signal via MICA waveform synchronized with Voice data via MIC
B24GroundAlwaysBelow 1 ohm

Scheme 1

Scheme 1
Scheme 1

Terminal specification (UVO)

Pin NOCommentsRemarksOutput voltage (V)
A5SPDIF_GNDNeeded connection to the carDigital Audio Output
A6SPDIF_DNNeeded connection to the carDigital Audio Output
A8Rheostat from vehicle +
A17Rheostat from vehicle
A18Remote supply for motorized antennaACC on9V ~ 18V
B1CAN_HIGHNeeded connection to the carCommunication with external amp
B4Steering Wheel Remote ControlSteering Wheel switch pushed0.5V ~ 3V
B6Rear View Camera Video SignalGearbox is in R-positionA waveform synchronized with video
B7Rear View Camera Power SupplyGearbox is in R-position3.2V ~ 3.45
B8AUX Right Sound SignalExternal Auxiliary device is Audio playing (At time of Aux jack use)A waveform synchronized with sound is output
B9AUX Reference GroundAlwaysBelow 1 ohm
B10Bluetooth MIC+Input the Voice Signal via MICA waveform synchronized with Voice data via MIC
B11AccessoryEngine switch on(ACC)11 ~ 14 V
B12BatteryAlways11 ~ 14 V
B13CAN_LOWNeeded connection to the carCommunication with external amp
B15Auto Light SignalNeeded connection to the car
B16Speed Sensor SignalEngine switch on(IGN), car is moved slowlyApprox. 5V Level Pulse Generation
B17Steering Wheel Remote Control GndAlwaysBelow 1 ohm
B18Rear View Camera Video GNDGearbox is in R-positionA wave for synchronized with video
B19R-PositionNeeded connection to the carGearbox is in R-position
B20AUX Signal Input DetectAuxiliary device is inserted0V(Low) --> 5V(High)
B21AUX Left Sound SignalExternal Auxiliary device is Audio playing (At time of Aux jack use)A waveform synchronized with sound is output
B22Bluetooth MICInput the Voice Signal via MICA waveform synchronized with Voice data via MIC
B23Rear View Camera Power GNDAlwaysBelow 1 ohm
B24GroundAlwaysBelow 1 ohm

Scheme 2

Scheme 2
Scheme 2
