Audio System: Removal & Installation Kia Soul I рестайлинг

Entertainment Systems 23 illustrations ~1229 words

Installation

  1. Connect the audio unit connectors and cable.
  2. Install the audio unit.
  3. Install the crash pad center facia panel.
  4. Install the upper tray.
  5. Check the audio system. NOTE: Make sure the audio head unit connectors are plugged in properly, and the antenna cable is connected properly.
  1. Connect the roof antenna cables and connectors.
  2. Install the rear roof trim.

Scheme 12

Scheme 12: Circuit Diagram

Scheme 13

Scheme 13

Scheme 14

Scheme 14: Removal

Scheme 15

Scheme 15

Scheme 16

Scheme 16

Scheme 17

Scheme 17

Scheme 18

Scheme 18

Scheme 19

Scheme 19
  1. Disconnect the negative (-) battery terminal.
  2. Remove the driver airbag module (A). (Refer to the «AIRBAG MODULES & CLOCK SPRING»(ref-537214) .
  3. Remove the steering wheel after loosening the nut and disconnecting the connector (A).
  4. Loosen the screws (4EA) on the opposite side of the steering wheel.
  5. Disconnect the audio remote control switch connector(A).
  6. Remove the audio remote control switch(B).
  1. Install the audio remote control switch on the steering wheel.
  2. Connect the audio remote control switch connector.
  3. Install the steering wheel.
  4. Install the driver airbag module.

Scheme 20

Scheme 20: Inspection
  1. Check for resistance between No. 6 and No. 7 terminals in each switch position.
SwitchConnector terminalResistance (±1%)
VOLUME DOWN6-76.81 kohms
VOLUME UP6-74.61 kohms
MODE6-72.11 kohms
SEEK DOWN6-71.11 kohms
SEEK UP6-7430 ohms
MUTE6-73.11 kohms

Scheme 21

Scheme 21: Circuit Diagram

R-1: Replace the audio head unit

  1. Check the same problems after replacing the audio head unit OK If Audio is normal operating, replace the audio head unit NG Check the vehicle wiring. (Refer to removal procedure. R-2)

Scheme 22

Scheme 22: R-2: Check the power connection of audio head unit

Scheme 23

Scheme 23
  1. Remove the audio head unit.
  2. Check the specified condition of terminal. OK Tester Connection Condition Specified Condition CON-B11/I11 <--> GND Always 9~12 V CON-B12/I12 <--> GND Always 9~12 V CON-B24/I24 <--> GND Always Below 1ohms NG Check again after repairing or replacing the Cable harness or Connector.

R-4: Replace the external amplifier

  1. Check the same problems after replacing the external amplifier OK If Audio is normal operating, replace the external amplifier NG Check the connectors of external amplifier power and interface (Refer to «R-5»(ref-537254-S30203397362013032200000) , «R-6»(ref-537254-S27188811012013032200000) and «R-8»(ref-537254-S34980380182013032200000) )

Scheme 24

Scheme 24: R-5: Check the external amplifier power cable
  1. Remove the external amplifier
  2. Check the specified condition of terminal. OK Tester Connection Condition Specified Condition CON-E1 <--> GND Always 9~12 V CON-E7 <--> GND Always 9~12 V CON-E15 <--> GND Always Below 1ohms NG Check again after repairing or replacing the Cable harness or Connector.

Scheme 25

Scheme 25: R-6: Check the external amplifier CAN interface

Scheme 26

Scheme 26
  1. Remove the audio head Unit.
  2. Remove the external amplifier
  3. Check the specified condition of terminal. OK Tester Connection Condition Specified Condition CON-I1 <--> CON-E5 Always Below 1ohms CON-I1 <--> GND CON-E5 <--> GND Always OPEN CON-I13 <--> CON-E6 Always Below 1ohms CON-I13 <--> GND CON-E6 <--> GND Always OPEN NG Check again after repairing or replacing the Cable harness or Connector.

Scheme 27

Scheme 27: R-8: Check the external amplifier S/PDIF connection

Scheme 28

Scheme 28
  1. Remove the audio head unit.
  2. Remove the external amplifier
  3. Check the specified condition of terminal. OK Tester Connection Condition Specified Condition CON-H6 <--> CON-E19 Always Below 1ohms CON-H6 <--> GND CON-E19<--> GND Always OPEN CON-H15 <--> CON-E18 Always Below 1ohms CON-H15 <--> GND CON-E18 <--> GND Always OPEN NG Check again after repairing or replacing the Cable harness or Connector.

Scheme 29

Scheme 29: R-11: Check the wiring harness and connector

Scheme 30

Scheme 30

Scheme 31

Scheme 31
  1. Remove the audio head unit
  2. Remove the external amplifier (For UVO) OK FOR PA-710S Tester Connection Condition Specified Condition CON-A1 <--> RL SPK + Always Below 1ohms CON-A10 <--> RL SPK - Always Below 1ohms CON-A2 <--> FL SPK + Always Below 1ohms CON-A11 <--> FL SPK - Always Below 1ohms CONA3 <--> FR SPK + Always Below 1ohms CON-A12 <--> FR SPK - Always Below 1ohms CON-A4 <--> RR SPK + Always Below 1ohms CON-A13 <--> RR SPK - Always Below 1ohms CON-A1, 2, 3, 4, 10, 11, 12, 13 <--> GND Always OPEN OK FOR UVO Tester Connection Condition Specified Condition CON-E12 <--> SUB WOOFER2 + Always Below 1ohms CON-E25 <--> SUB WOOFER2 - Always Below 1ohms CON-E13 <--> SUB WOOFER1 + Always Below 1ohms CON-E26 <--> SUB WOOFER1 - Always Below 1ohms CON-F7 <--> CENTER SPK + Always Below 1ohms CON-F14 <--> CENTER SPK - Always Below 1ohms CON-G1 <--> RR DOOR SPK + Always Below 1ohms CON-G7 <--> RR DOOR SPK - Always Below 1ohms CON-G2 <--> RL DOOR SPK + Always Below 1ohms CON-G8 <--> RL DOORSPK - Always Below 1ohms CON-G3 <--> FR SPK + Always Below 1ohms CON-G9 <--> FR SPK - Always Below 1ohms CON-G4 <--> FL SPK + Always Below 1ohms CON-G10 <--> FL SPK - Always Below 1ohms CON-G5 <--> FR DOOR SPK + Always Below 1ohms CON-G11 <--> FR DOOR SPK - Always Below 1ohms CON-G6 <--> FL DOOR SPK + Always Below 1ohms CON-G12 <--> FL DOOR SPK - Always Below 1ohms CON-E12, 13, 25, 26/F7, 14/G1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12 <--> GND Always OPEN NG Check again after repairing or replacing the Cable harness or Connector.

Scheme 32

Scheme 32: R-12: Check the wiring harness and connector

Scheme 33

Scheme 33

Scheme 34

Scheme 34
  1. Remove the audio head unit
  2. Remove the external amplifier (For UVO)
  3. Check the output of audio head unit and external amplifier using the oscilloscope OK FOR PA-710S Tester Connection Condition Specified Condition CON-A1 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-A10 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-A2 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-A11 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-A3 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-A12 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-A4 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-A13 <--> GND Audio sound is being produced A waveform synchronized with sound is output OK FOR UVO Tester Connection Condition Specified Condition CON-E12 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-E25 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-E13 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-E26 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-F7 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-F14 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-G1 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-G7 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-G2 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-G8 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-G3 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-G9 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-G4 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-G10 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-G5 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-G11 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-G6 <--> GND Audio sound is being produced A waveform synchronized with sound is output CON-G12 <--> GND Audio sound is being produced A waveform synchronized with sound is output NG Check again after repairing or replacing the Cable harness or Connector.
