Blower System Kia Soul I рестайлинг

Scheme 45

1. Connect the battery voltage and check the blower motor rotation.
2. If the blower motor voltage is not operated well, substitute with a known-good blower motor and check for proper operation.
3. If the problem is corrected, replace the blower motor.

Scheme 46

1. Disconnect the negative (-) battery terminal.
2. Remove the crashpad lower cover. Refer to " «CRASH PAD»(ref-537227-S36224571332013032200000) ")
3. Disconnect the connector (A) of the blower motor.
4. Remove the blower motor (B) after loosening the mounting screws.
5. Installation is the reverse order of removal.

Scheme 47

1. Ignition "ON"
2. Manually operate the control switch and measure the voltage of blower motor.
3. Select the control switch to raise voltage until high speed. VOLTAGE SPECIFICATION Fan Motor Voltage Manual First speed 3.8 ±0.5V Second speed 5.0 ±0.5V Third speed 6.2 ±0.5V Fourth speed 7.4 ±0.5V Fifth speed 8.6 ±0.5V Sixth speed 9.8 ±0.5V Seventh speed 11.0 ±0.5V eighth speed Battery
4. If the measured voltage is not specification, substitute with a known-good power mosfet and check for proper operation.
5. If the problem is corrected, replace the power mosfet.

Scheme 48

1. Disconnect the negative (-) battery terminal.
2. Remove the crash pad lower cover. (Refer to " «LOWER PANEL REPLACEMENT»(ref-537227-S19454244452013032200000) ")
3. Disconnect the power mosfet connector (A) and then remove the power mosfet (B) after loosening the mounting screws.
4. Installation is the reverse order of removal.

Scheme 49

1. Measure terminal-to-terminal resistance of the blower resistor.
2. If measured resistance is not within specification, the blower resistor must be replaced. (After removing the resistor)

Scheme 50

1. Disconnect the negative (-) battery terminal.
2. Remove the crashpad lower panel. (refer to «LOWER PANEL REPLACEMENT»(ref-537227-S19454244452013032200000) )
3. Disconnect the connector and then remove the blower resistor (A).
4. Installation is the reverse order of removal.

Description

This has particle filter which eliminates foreign materials and odor. The particle filter includes odor filter as well as conventional dust filter to ensure comfortable interior environment.

Scheme 51

Scheme 52

Scheme 53

1. Loosen the mount screw and then remove the glove box (A).
2. Remove the filter cover (A) with pushing the knob.
3. Replace the air filter (B), install it after making sure of the direction of air filter.
4. Installation is the reverse order of removal. NOTE: In case of driving in an air-polluted area or rugged terrain, check and replace the air filter as frequently as possible.

Scheme 54

1. The intake actuator is located at the blower unit.
2. It regulates the intake door by signal from control unit.
3. Pressing the intake selection switch will shift between recirculation and fresh air modes.

Scheme 55

1. Ignition "OFF"
2. Disconnect the intake actuator connector.
3. Verify that the actuator operates to the fresh position when connecting 12V to the terminal 3 and grounding terminal 4.
4. Verify that the intake actuator operates to the recirculation position when connecting in the reverse.
5. If the intake actuator is not operated well, substitute with a known-good intake actuator and check for proper operation.
6. If the problem is corrected, replace the intake actuator.

Scheme 56

1. Disconnect the negative (-) battery terminal.
2. Remove the crash pad. (Refer to " «CRASH PAD»(ref-537227-S36224571332013032200000) ")
3. Disconnect the intake actuator connector.
4. Loosen the mounting screw and then remove the intake actuator (B) from the blower unit.
5. Installation is the reverse order of removal.
