Specification

Temperature(°C/°F)Resistance(kohms)
10/1445.9
0/3225
20/688.43
40/1043.27
60/1401.4
80/1760.7

* RESISTANCE VALUE OF ENGINE COOLANT TEMPERATURE SENSOR AS A FUNCTION OF TEMPERATURE

Scheme 73

Scheme 73: Diagnostic Circuit Diagram

Scheme 74

Scheme 74: Monitor Scantool Data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "Water temperature sensor" parameter.
  4. Is the Water temperature sensor normal? YES Go to " «INSPECTION AND REPAIR»(ref-537307-S26940526132013032200000) " procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537307-S14752129552013032200000) " procedure.
Temperature(°C/°F)Resistance(kohms)
10/1445.9
0/3225
20/688.43
40/1043.27
60/1401.4
80/1760.7

* RESISTANCE VALUE OF ENGINE COOLANT TEMPERATURE SENSOR AS A FUNCTION OF TEMPERATURE

Scheme 75

Scheme 75: Diagnostic Circuit Diagram

Scheme 76

Scheme 76: Monitor Scantool Data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "Water temperature sensor" parameter.
  4. Is the Water temperature sensor normal? YES Go to " «INSPECTION AND REPAIR»(ref-537307-S29351149872013032200000) " procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537307-S05908896062013032200000) " procedure.
Door positionVoltage
FRE0.3±0.15V
REC4.65±0.15V

* VOLTAGE VALUE OF INTAKE POTENTIOMETER AS A FUNCTION OF POSITION OF INTAKE DOOR

Scheme 77

Scheme 77: Diagnostic Circuit Diagram

Scheme 78

Scheme 78: Monitor Scantool data
  1. Check Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal temperature after engine start. Select "Intake Potentiometer" parameter on the current data with scantool. Perform Actuation Test for Air Inlet Mode Selection - Recirculation/Fresh in order. With performing Actuation test, check that the value of each position sensors are changing. Specification: Recirculation: About 90%, Fresh: About 10%. Are the value of each position sensors changed when performing actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537307-S12804401842013032200000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-537307-S29351149872013032200000) " procedure.
Door positionVoltage
FRE0.3±0.15V
REC4.65±0.15V

* VOLTAGE VALUE OF INTAKE POTENTIOMETER AS A FUNCTION OF POSITION OF INTAKE DOOR

Scheme 79

Scheme 79: Diagnostic Circuit Diagram

Scheme 80

Scheme 80: Monitor Scantool data
  1. Check Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal temperature after engine start. Select "Intake Potentiometer" parameter on the current data with scantool. Perform Actuation Test for Air Inlet Mode Selection - Recirculation/Fresh in order. With performing Actuation test, check that the value of each position sensors are changing. Specification: Recirculation: About 90%, Fresh: About 10%. Are the value of each position sensors changed when performing actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537307-S12235678952013032200000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-537307-S01907159152013032200000) " procedure.
Temperature(°C/°F)Resistance(kohms)
20/-4285.6
10/14164
0/3297.7
10/5059.67
20/6837.4
30/8624.1
40/10415.9
50/12210.8

* RESISTANCE VALUE OF INCAR TEMP SENSOR AS A FUNCTION OF TEMPERATURE

Scheme 81

Scheme 81: Diagnostic Circuit Diagram

Scheme 82

Scheme 82: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "In-car temperature sensor 1" parameter.
  4. Is the Incar temperature sensor normal? YES This is a intermittent problem caused by poor contact of component or A/C Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537307-S24472923562013032200000) " procedure. NO Substitute with a known good In-Car Temp. Sensor and check for proper operation. If the problem is corrected, replace In-Car Temp. Sensor and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537307-S24472923562013032200000) " procedure.
Temperature(°C/°F)Resistance(kohms)
20/-4285.6
10/14164
0/3297.7
10/5059.67
20/6837.4
30/8624.1
40/10415.9
50/12210.8

* RESISTANCE VALUE OF INCAR TEMP SENSOR AS A FUNCTION OF TEMPERATURE

Scheme 83

Scheme 83: Diagnostic Circuit Diagram

Scheme 84

Scheme 84: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "In-car temperature sensor 1" parameter.
  4. Is the Incar temperature sensor normal? YES This is a intermittent problem caused by poor contact of component or A/C Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537307-S12716065402013032200000) " procedure. NO Substitute with a known good In-Car Temp. Sensor and check for proper operation. If the problem is corrected, replace In-Car Temp. Sensor and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537307-S12716065402013032200000) " procedure.
Temperature(°C/°F)Resistance(kohms)
20/-4271.4
0/3295.1
25/7730
50/12211
60/1407.58

* RESISTANCE VALUE OF AMBIENT TEMP.SENSOR AS A FUNCTION OF TEMPERATURE

Scheme 85

Scheme 85: Diagnostic Circuit Diagram

Scheme 86

Scheme 86: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "Ambient Air Temperature sensor" parameter.
  4. Is the ambient sensor abnormal? YES Go to " «INSPECTION AND REPAIR»(ref-537307-S08346837902013032200000) " procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537307-S27126343642013032200000) " procedure.
Temperature(°C/°F)Resistance(kohms)
20/-4271.4
0/3295.1
25/7730
50/12211
60/1407.58

* RESISTANCE VALUE OF AMBIENT TEMP.SENSOR AS A FUNCTION OF TEMPERATURE

Scheme 87

Scheme 87: Diagnostic Circuit Diagram

Scheme 88

Scheme 88: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "Ambient Air Temperature sensor" parameter.
  4. Is the ambient sensor abnormal? YES Go to " «INSPECTION AND REPAIR»(ref-537307-S16470739302013032200000) " procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537307-S14298838772013032200000) " procedure.
Temperature(°C/°F)Resistance(kohms)
20/-443.3
0/3227.6
10/5018
20/6812.1
30/868.3
40/1045.8

* RESISTANCE VALUE OF EVAPORATOR SENSOR AS A FUNCTION OF TEMPERATURE

Scheme 89

Scheme 89: Diagnostic Circuit Diagram

Scheme 90

Scheme 90: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "Evaporator sensor" parameter on scantool.
  4. Is the Evaporator Sensor abnormal? YES Go to " «INSPECTION AND REPAIR»(ref-537307-S13932959212013032200000) " procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537307-S18275012012013032200000) " procedure.
Door positionVoltage
Max. cool0.3±0.15V
Max. warm4.7±0.15V

* VOLTAGE VALUE OF AIR MIX POTENTIOMETER AS A FUNCTION OF TEMP DOOR POSITION

Scheme 91

Scheme 91: Diagnostic Circuit Diagram

Scheme 92

Scheme 92: Monitor Scantool data
  1. Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal engine temperature after engine starts. Select and monitor "Air Mix Door Potentioner-Driver" parameter on scantool. Select and perform Actuation test Air Mix Door Potentioner-Driver - 0% / 50% / 100% in order. With performing Actuation test, check that the value of Air Mix Door Potentiometer follows is changed and close to the value of Actuation Test. Specification: Check that the value of Air Mix Door Potentiometer at current data should be close to the value of the actuation test. Does the value of current data follow in accordance with the each actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537307-S40068368332013032200000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-537307-S25790680972013032200000) " procedure.
Door positionVoltage
Max. cool0.3±0.15V
Max. warm4.7±0.15V

* VOLTAGE VALUE OF AIR MIX POTENTIOMETER AS A FUNCTION OF TEMP DOOR POSITION

Scheme 93

Scheme 93: Diagnostic Circuit Diagram

Scheme 94

Scheme 94: Monitor Scantool data
  1. Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal engine temperature after engine starts. Select and monitor "Air Mix Door Potentioner-Driver" parameter on scantool. Select and perform Actuation test Air Mix Door Potentioner-Driver - 0% / 50% / 100% in order. With performing Actuation test, check that the value of Air Mix Door Potentiometer follows is changed and close to the value of Actuation Test. Specification: Check that the value of Air Mix Door Potentiometer at current data should be close to the value of the actuation test. Does the value of current data follow in accordance with the each actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537307-S11555304102013032200000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-537307-S18479275352013032200000) " procedure.
Mode Door PositionVoltage
VENT0.3±0.15V
BI-LEVEL1.4±0.4V
FLOOR2.5±0.4V
MIX3.6±0.4V
DEF4.7±0.15V

* VOLTAGE VALUE OF POTENTIOMETER AS A FUNCTION OF MODE DOOR POSITION

Scheme 95

Scheme 95: Diagnostic Circuit Diagram

Scheme 96

Scheme 96: Monitor Scantool data
  1. Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal engine temperature after engine starts. Select and monitor "Direction Potentiometer" parameter on scantool. Select and perform Actuation test Driver Mode Door - Face / Foot / Defrost in order. Check that the value of all the parameters are changed when performing the actuation test. Specification: Face - About below 10%, Foot: About 50%, Defrost: About 90%. Are all the parameters changed when performing Actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537307-S19982995492013032200000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-537307-S03894291452013032200000) " procedure.
Temperature(°C/°F)Resistance(kohms)
20/-443.3
0/3227.6
10/5018
20/6812.1
30/868.3
40/1045.8

* RESISTANCE VALUE OF EVAPORATOR SENSOR AS A FUNCTION OF TEMPERATURE

Scheme 97

Scheme 97: Diagnostic Circuit Diagram

Scheme 98

Scheme 98: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "Evaporator sensor" parameter on scantool.
  4. Is the Evaporator Sensor abnormal? YES Go to " «INSPECTION AND REPAIR»(ref-537307-S11829542482013032200000) " procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537307-S03565925622013032200000) " procedure.
Mode Door PositionVoltage
VENT0.3±0.15V
BI-LEVEL1.4±0.4V
FLOOR2.5±0.4V
MIX3.6±0.4V
DEF4.7±0.15V

* VOLTAGE VALUE OF POTENTIOMETER AS A FUNCTION OF MODE DOOR POSITION

Scheme 99

Scheme 99: Diagnostic Circuit Diagram

Scheme 100

Scheme 100: Monitor Scantool data
  1. Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal engine temperature after engine starts. Select and monitor "Direction Potentiometer" parameter on scantool. Select and perform Actuation test Driver Mode Door - Face / Foot / Defrost in order. Check that the value of all the parameters are changed when performing the actuation test. Specification: Face - About below 10%, Foot: About 50%, Defrost: About 90%. Are all the parameters changed when performing Actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537307-S39376548992013032200000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-537307-S06388046732013032200000) " procedure.
Door positionVoltage
Max. cool0.3±0.15V
Max. warm4.7±0.15V

* VOLTAGE VALUE OF AIR MIX POTENTIOMETER AS A FUNCTION OF TEMP DOOR POSITION

Scheme 101

Scheme 101: Diagnostic Circuit Diagram

Scheme 102

Scheme 102: Monitor Scantool data
  1. Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal engine temperature after engine starts. Select and monitor "Air Mix Door Potentioner-Driver" parameter on scantool. Select and perform Actuation test Air Mix Door Potentioner-Driver - 0% / 50% / 100% in order. Check that the value of all the parameters are changed when performing the actuation test. Specification: Check that the value of Air Mix Door Potentiometer at current data should be close to the value of the actuation test. Does the value of current data follow in accordance with the each actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537307-S18869703732013032200000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-537307-S28289038402013032200000) " procedure.
Door positionVoltage
FRE0.3±0.15V
REC4.65±0.15V

* VOLTAGE VALUE OF INTAKE POTENTIOMETER AS A FUNCTION OF POSITION OF INTAKE DOOR

Scheme 103

Scheme 103: Diagnostic Circuit Diagram

Scheme 104

Scheme 104: Monitor Scantool data
  1. Check Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal temperature after engine start. Select "Intake Potentiometer" parameter on the current data with scantool. Perform Actuation Test for Air Inlet Mode Selection - Recirculation/Fresh in order. With performing Actuation test, check that the value of each position sensors are changing. Specification: Recirculation: About 90%, Fresh: About 10%. Are the value of each position sensors changed when performing actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537307-S00116092682013032200000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-537307-S36096948262013032200000) " procedure.
Mode Door PositionVoltage
VENT0.3±0.15V
BI-LEVEL1.4±0.4V
FLOOR2.5±0.4V
MIX3.6±0.4V
DEF4.7±0.15V

* VOLTAGE VALUE OF POTENTIOMETER AS A FUNCTION OF MODE DOOR POSITION

Scheme 105

Scheme 105: Diagnostic Circuit Diagram

Scheme 106

Scheme 106: Monitor Scantool data
  1. Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal engine temperature after engine starts. Select and monitor "Direction Potentiometer" parameter on scantool. Select and perform Actuation test Driver Mode Door - Face / Foot / Defrost in order. Check that the value of all the parameters are changed when performing the actuation test. Specification: Face - About below 10%, Foot: About 50%, Defrost: About 90%. Are all the parameters changed when performing Actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit. Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-537307-S16893185042013032200000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-537307-S20581234802013032200000) " procedure.
