Restraints (Except Troubleshooting): Wiring Kia Sorento I рестайлинг

WIRING PRECAUTIONS

SRS wiring can be identified by special yellow outer covering (except the SRS circuits under the front seats and the SRS circuits in the FEM of engine room).

Observe the instructions described in this section.

Scheme 32

Scheme 33

1. Never attempt to modify, splice, or repair SRS wiring. If there is an open or damage in SRS wiring, replace the harness.
2. Be sure to install the harness wires so that they are not pinched, or interfere with other parts.
3. Make sure all SRS ground locations are clean, and grounds are securely fastened for optimum metal-to-metal contact. Poor grounding can cause intermittent problems that are difficult to diagnose.

Scheme 34

1. When using electrical test equipment, insert the probe of the tester into the wire side of the connector. Do not insert the probe of the tester into the terminal side of the connector, and do not tamper with the connector.
2. Use a u-shaped probe. Do not insert the probe forcibly.
3. Use specified service connectors for troubleshooting. Using improper tools could cause an error in inspection due to poor metal contact.
