Restraints (Except Troubleshooting): Removal & Installation Kia Sorento I рестайлинг

COMPONENT REPLACEMENT AFTER DEPLOYMENT

Note. Before doing any SRS repairs, use the Hi-Scan Pro to check for DTCs. Refer to appropriate Diagnostic Trouble Code for repairing of the related DTCs.

When the front airbag(s) deployed after a collision, replace the following items.

1. SRSCM
2. Deployed airbag(s)
3. Seat belt pretensioner(s)
4. Front impact sensor
5. SRS wiring harnesses
6. Inspect the clock spring for heat damage.
7. If any damage found, replace the clock spring.

When the seat belt pretensioner(s) deployed after a collision, replace the following items.

1. Seat belt pretensioner(s)
2. SRSCM (if B1658 detected)
3. Front impact sensor
4. SRS wiring harnesses

When the curtain airbag(s) deployed after a collision, replace the following items.

1. SRSCM
2. Deployed airbag(s)
3. Side impact sensor(s) for the deployed side(s)
4. SRS wiring harnesses

After the vehicle is completely repaired, confirm the SRS airbag system is OK.

1. Turn the ignition switch ON, the SRS indicator should come on for about 6 seconds and then go off.

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

INSTALLATION

1. Remove the ignition key from the vehicle.
2. Disconnect the battery negative cable and wait for at least three minutes before beginning work.
3. Install the SRSCM with the SRSCM mounting bolt and nuts. Tightening torque (SRSCM Mounting bolt): 1.0-1.4 kgf.m (10.2-13.8 N.m, 7.5-10.2 lb.ft) NOTE: Use new mounting bolts when replacing the SRSCM after a collision.
4. Connect the SRSCM harness connector completely with pushing the connector locking lever.
5. Install the console lid cover. Refer to «BODY (INTERIOR AND EXTERIOR)»(ref-278816) .
6. Connect the DAB, PAB, KAB, CAB and BPT connectors.
7. Reconnect the battery negative cable.
8. After installing the SRSCM, confirm proper system operation: Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off.

1. Remove the ignition key from the vehicle.
2. Disconnect the battery negative cable and wait for at least three minutes.
3. Tighten the CAB mounting bolts (6EA) and nut (1EA). Tightening torque: 0.8-1.2 kgf.m (7.8-11.8 N.m, 5.8-8.7 lb.ft) CAUTION: Never twist the airbag module when installing it. If the module is twisted, airbag module may operate abnormally.
4. Connect the CAB connector.
5. Install the following parts. Refer to «BODY (INTERIOR AND EXTERIOR)»(ref-278816) . Side trim, Roof trim
6. Reconnect the battery negative cable.
7. After installing the Curtain Airbag (CAB), confirm proper system operation: Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off.

1. Remove the ignition key from the vehicle.
2. Disconnect the battery negative cable and wait for at least three minutes.
3. Connect the KAB connector.
4. Tighten the KAB mounting nuts (4EA). Tightening torque: 1.9-2.7 kgf.m (18.6-26.7 N.m, 13.7-19.8 lb.ft) CAUTION: Never twist the airbag module when installing it. If the module is twisted, airbag module may operate abnormally.
5. Install the following parts. Refer to «BODY (INTERIOR AND EXTERIOR)»(ref-278816) . Crash pad lower panel.
6. Reconnect the battery negative cable.
7. After installing the Knee Airbag (KAB), confirm proper system operation: Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off.

1. Remove the ignition key from the vehicle.
2. Disconnect the battery negative cable and wait for at least three minutes.
3. Install the Seat Belt Pretensioner (BPT) with a screw.
4. Connect the Seat Belt Pretensioner (BPT) connector.
5. Install the upper anchor bolt. Tightening torque (Seat Belt Anchor Bolt): 4.0-5.5 kgf.m (39.2-53.9 N.m, 28.9-39.8 lb.ft)
6. Install the center pillar trim.
7. Install the door scuff trim.
8. Install the lower anchor bolt. Tightening torque: 4.0-5.5 kgf.m (39.2-53.9 N.m, 28.9-39.8 lb.ft)
9. Reconnect the battery negative cable.
10. After installing the Seat Belt Pretensioner (BPT), confirm proper system operation: Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off.

REMOVAL

Scheme 30

1. Disconnect the battery negative cable, and wait for at least three minutes before beginning work.
2. Remove the Front bumper seal board.
3. Remove the Front Impact Sensor mounting bolt.
4. Disconnect the Front Impact Sensor connector.

1. Install the new Front Impact Sensor.
2. Tighten the Front Impact Sensor mounting bolt. Tightening torque: 1.0-1.4 kgf.m (10.2-13.8 N.m, 7.5-10.2 lb.ft)
3. Connect the Front Impact Sensor connector.
4. Install the Front bumper seal board.
5. Reconnect the battery negative cable.
6. After installing the Front Impact Sensor, confirm proper system operation: Turn the ignition switch ON the SRS indicator light should be turned on for about six seconds and then go off.

Scheme 31

1. Disconnect the battery negative cable, and wait for at least three minutes before beginning work.
2. Remove the lower anchor bolt.
3. Remove the following parts. Refer to «BODY (INTERIOR AND EXTERIOR)»(ref-278816) . Door scuff trim, Center pillar trim
4. Disconnect the Side Impact Sensor connector and remove the Side Impact Sensor mounting bolt.

1. Install the new Side Impact Sensor with the bolt then connect the SRS harness connector to the Side Impact Sensor. Tightening torque: 1.0-1.4 kgf.m (10.2-13.8 N.m, 7.5-10.2 lb.ft)
2. Install the center pillar trim. Refer to «BODY (INTERIOR AND EXTERIOR)»(ref-278816) .
3. Install the door scuff trim. Refer to «BODY (INTERIOR AND EXTERIOR)»(ref-278816) .
4. Install the lower anchor bolt.
5. Reconnect the battery negative cable.
6. After installing the Side Impact Sensor, confirm proper system operation: Turn the ignition switch ON, the SRS indicator light should be turned on for about six seconds and then go off.
