Evaporative Emission Control System: Removal & Installation Kia Sedona II facelift

INSTALLATION

Installation is in reverse order of removal.

Torque : 1.7 ~ 2.6kgf.m (16.7 ~ 25.5N.m, 12.3 ~ 18.8lbf.ft)

Scheme 18

Scheme 19

1. Remove the rear left wheel house inner cover. (Refer to «TIRES/WHEELS»(ref-380180) )
2. Disconnect the vacuum hose (A).
3. Remove the fuel tank air filter (B) with unscrewing the mounting bolts (C).
4. Install a new fuel tank air filter and connect the canister close valve connector.
