Engine Control System: Specifications Kia Sedona II facelift

Testing & Diagnostics 2 illustrations

SPECIFICATION

[THROTTLE POSITION SENSOR]

Throttle Angle (°)Output Voltage (V) [Vref = 5.0V]
TPS1TPS2
0V5.0V
10°0.5V4.5V
20°0.9V4.1V
30°1.4V3.6V
40°1.8V3.2V
50°2.3V2.7V
60°2.7V2.3V
70°3.2V1.8V
80°3.6V1.4V
90°4.1V0.9V
100°4.5V0.5V
110°5.0V0V

VOLTAGE SPECIFICATION

ItemSensor Resistance
TPS14.0 ~ 6.0kohms at 20°C (68°F)
TPS22.72 ~ 4.08kohms at 20°C (68°F)

RESISTANCE SPECIFICATION

Scheme 25

Scheme 25

[ETC MOTOR]

ItemSensor Resistance
Coil Resistance (ohms)1.275 ~ 1.725ohms at 20°C (68°F)

RESISTANCE SPECIFICATION

Scheme 26

Scheme 26: SCHEMATIC DIAGRAM

FAIL-SAFE MODE

ModeDescriptionSymptomPossible Cause
MODE 1FORCED ENGINE SHUTDOWNEngine stopETC system can't proceed reliable algorithm procedure Fatal PCM internal programming error Faulty intake system or throttle body
MODE 2FORCED IDLE & POWER MANAGEMENTForced idle state controlled by fuel quantity regulation and ignition timing adjustmentETC system can't control engine power via throttle device Disabled throttle control or broken throttle position information
MODE 3FORCED IDLEForced idle state and no response for accelerator activationNo information about the accelerator position Malfunctioning APS 1 and 2, faulty A/D converter or internal controller
MODE 4LIMIT PERFORMANCE & POWER MANAGEMENTEngine power is determined by accelerator position and idle power requirement (Limited vehicle running)ETC system can't securely control engine power
MODE 5LIMIT PERFORMANCEEngine power varies with accelerator position, but driver perceives lack of engine power. MIL ON (Normal vehicle running)Not reliable accelerator position signal or bad maximum power generation Faulty APS, ignition voltage or internal controller
MODE 6NORMALNormal

FAIL-SAFE
