MECHANICAL SYSTEM
CLUTCHES AND BRAKES FOR EACH RANGE
| UD Clutch | OD Clutch | 2ND Brake | LR Brake | REV Clutch | RED Brake | DIR Clutch | OWC 1 | OWC 2 | ||
|---|---|---|---|---|---|---|---|---|---|---|
| P | O | O | ||||||||
| R | O | O | O | |||||||
| N | O | O | ||||||||
| D | 1st | O | O | O | ||||||
| 2nd | O | O | O | |||||||
| 3rd | O | O | O | |||||||
| 4th | O | O | O | |||||||
| 5th | O | O | O | |||||||
| (• : Locked when driving) | ||||||||||
CLUTCHES AND BRAKES RANGE CLUTCHES AND BRAKES RANGE
FUNCTIONS OF CLUTCHES AND BRAKES
| Element | Sign | Function |
|---|---|---|
| Underdrive clutch | UD | Connect the input shaft with the underdrive sun gear |
| Reverse clutch | REV | Connect the input shaft with the reverse sun gear |
| Overdrive clutch | OD | Connect the input shaft with the overdrive carrier |
| Direct clutch | DIR | Connect the direct sun gear with the direct carrier |
| Low & Reverse brake | LR | Fix the planetary gear and the overdrive carrier |
| 2nd brake | 2ND | Fix the reverse sun gear |
| Reduction brake | RED | Fix the direct sun gear |
| One way clutch 1 | OWC 1 | Control the rotational direction of the low & reverse ring gear |
| One way clutch 2 | OWC 2 | Control the rotational direction of the direct sun gear |
ELEMENT FUNCTION ELEMENT FUNCTION
