Automatic Transaxle Diagnosis: Specifications Kia Sedona II facelift

Automatic Trans 95 illustrations ~2198 words

Specification

Temperature °C (°F)Resistance (kohms)Temperature °C (°F)Resistance (kohms)
40 (-40)139.580 (176)1.08
20 (-4)47.7100 (212)0.63
0 (32)18.6120 (248)0.38
20 (68)8.1140 (284)0.25
40 (104)3.8160 (320)0.16
60 (140)1.98

RESISTANCE SPECIFICATION

Scheme 616

Scheme 616: Schematic Diagram

Scheme 617

Scheme 617: Monitor Scantool Data

Scheme 618

Scheme 618

Scheme 619

Scheme 619
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "TRANSAXLE FLUID TEMPERATURE SENSOR" parameter on the scantool Specification : Increasing Gradually
  4. Does "TRANSAXLE FLUID TEMPERATURE SENSOR" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION VEHICLE REPAIR»(ref-380250-S29076730642010121800000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-380250-S33100719312010121800000) " procedure
Temperature °C (°F)Resistance (kohms)Temperature °C (°F)Resistance (kohms)
40 (-40)139.580 (176)1.08
20 (-4)47.7100 (212)0.63
0 (32)18.6120 (248)0.38
20 (68)8.1140 (284)0.25
40 (104)3.8160 (320)0.16
60 (140)1.98

RESISTANCE SPECIFICATION

Scheme 620

Scheme 620: Schematic Diagram

Scheme 621

Scheme 621: Monitor Scantool Data

Scheme 622

Scheme 622

Scheme 623

Scheme 623
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "TRANSAXLE FLUID TEMPERATURE SENSOR" parameter on the scantool Specification : Increasing Gradually
  4. Does "TRANSAXLE FLUID TEMPERATURE SENSOR" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION VEHICLE REPAIR»(ref-380250-S32788632572010121800000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-380250-S28130320562010121800000) " procedure
TEMP. (°F)RESISTANCE (kohms)TEMP. (°F)RESISTANCE (kohms)
40 (-40)139.580 (176)1.08
20 (-4)47.7100 (212)0.63
0 (32)18.6120 (248)0.38
20 (68)8.1140 (284)0.25
40 (104)3.8160 (320)0.16
60 (140)1.98

RESISTANCE SPECIFICATION

Scheme 624

Scheme 624: Schematic Diagram

Scheme 625

Scheme 625: Monitor Scantool Data

Scheme 626

Scheme 626

Scheme 627

Scheme 627
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "TRANSAXLE FLUID TEMPERATURE SENSOR" parameter on the scantool Specification : Increasing Gradually
  4. Does "TRANSAXLE FLUID TEMPERATURE SENSOR" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION VEHICLE REPAIR»(ref-380250-S01319788502010121800000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-380250-S33831246162010121800000) " procedure

Input shaft & Output shaft speed sensor

  1. Type : Hall sensor
  2. Current consumption : 22mA (MAX)
  3. Sensor body and sensor connector have been unified as one.

Scheme 628

Scheme 628: Signal Waveform

Scheme 629

Scheme 629: Monitor Scantool Data

Scheme 630

Scheme 630
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "INPUT SPEED SENSOR" parameter on the scantool
  4. Driving at speed of over 19 Mile (30 km)/h Specification : Increasing Gradually
  5. Does "Input speed sensor" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION VEHICLE REPAIR»(ref-380250-S37929454882010121800000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-380250-S20479845062010121800000) " procedure

Input shaft & Output shaft speed sensor

  1. Type : Hall sensor
  2. Current consumption : 22mA (MAX)
  3. Sensor body and sensor connector have been unified as one.

Scheme 631

Scheme 631: Schematic Diagram

Scheme 632

Scheme 632: Signal Waveform

Scheme 633

Scheme 633: Monitor Scantool Data

Scheme 634

Scheme 634
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "OUTPUT SPEED SENSOR" parameter on the scantool
  4. Driving at speed of over 19 Mile (30 km)/h Specification : Increasing Gradually
  5. Does "Output speed sensor" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION VEHICLE REPAIR»(ref-380250-S37805883802010121800000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-380250-S01022552482010121800000) " procedure

Check Torque Converter Clutch Solenoid Valve

  1. Connect scantool to data link connector (DLC)
  2. Ignition "ON" & Engine "OFF".
  3. Select A/T Solenoid valve Actuator test and Operate Actuator test.
  4. Can you hear operating sound for using TCC SOLENOID VALVE Actuator Testing Function? YES Go to «Check Oil Pressure»(ref-380250-S01205228202011022300000) as below. NO Replace "TCC SOLENOID VALVE" as necessary and Go to " «VERIFICATION VEHICLE REPAIR»(ref-380250-S04710694162010121800000) " procedure

Scheme 635

Scheme 635: Check Oil Pressure
  1. Connect Oil pressure gauge to "DA" port.
  2. Engine "ON".
  3. After connecting Scantool and monitor the "TCC SOLENOID VALVE DUTY" parameter on the Scantool data list.
  4. Operate vehicle with 3rd or 4th gear and operate the "TCC SOLENOID VALVE DUTY" more than 85%. Specification : Oil pressure gauge approx 735.4960KPa (7.5kg/cm 2 )- (In condition that TCC SOL. DUTY > 85%)
  5. Is oil pressure value within specifications? YES Repair TORQUE CONVERTER CLUTCH (REPLACE Torque Converter) as necessary and Go to " «VERIFICATION VEHICLE REPAIR»(ref-380250-S04710694162010121800000) " procedure. NO Replace A/T ass'y (possible to BODY CONTROL VALVE faulty) as necessary and Go to " «VERIFICATION VEHICLE REPAIR»(ref-380250-S04710694162010121800000) " procedure.
  1. Connect scantool to data link connector (DLC)
  2. Ignition "ON" & Engine "OFF".
  3. Select A/T Solenoid valve Actuator test and Operate Actuator test.
  4. Can you hear operating noise for using TCC SOLENOID VALVE Actuator Testing Function? YES Go to «Check Oil Pressure»(ref-380250-S20811660382011022300000) as below. NO Repair or Replace as necessary and then go to " «VERIFICATION VEHICLE REPAIR»(ref-380250-S26678515622010121800000) " procedure

Scheme 636

Scheme 636: Check Oil Pressure
  1. Connect Oil pressure gauge to "DR" port.
  2. Ignition "ON" & Engine "OFF".
  3. After connecting Scantool and monitor the "TCC SOLENOID VALVE DUTY" parameter on the Scantool data list.
  4. Select 1st gear and accelerate Engine speed to 2500 rpm
  5. Measure oil pressure Specification : approx. 598.2034KPa (6.1kg/cm 2 )
  6. Is oil pressure value within specifications? YES Repair TORQUE CONVERTER CLUTCH (REPLACE Torque Converter) as necessary and Go to " «VERIFICATION VEHICLE REPAIR»(ref-380250-S26678515622010121800000) " procedure. NO Replace A/T ass'y (possible to BODY CONTROL VALVE faulty) as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380250-S26678515622010121800000) " procedure.

Solenoid Valve for Pressure Control

  1. Sensor type : Normal open 3-way
  2. Operating temperature : -22~266°F (-30°C~130°C)
  3. Frequency : LR, 2ND, UD, OD, RED : 61.27Hz (at the ATF temp. -20°C above)

DCC : 30.64Hz

KM series : 35Hz

  1. Internal resistance : 2.7~3.4ohms (68°F or 20°C)
  2. Surge voltage : 56 V

Scheme 637

Scheme 637: Schematic Diagram

Scheme 638

Scheme 638: Signal Waveform

Scheme 639

Scheme 639: Monitor Scantool Data

Scheme 640

Scheme 640

Scheme 641

Scheme 641

Scheme 642

Scheme 642

Scheme 643

Scheme 643

Scheme 644

Scheme 644

Scheme 645

Scheme 645
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "TCC SOL. VALVE" parameter on the scantool
  4. Select "D RANGE" and Operate "TCC SOLENOID DUTY" more than 40%.
  5. Does "TCC SOLENOID DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION VEHICLE REPAIR»(ref-380250-S34950491582010121800000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-380250-S30711124042010121800000) " procedure

Solenoid Valve for Pressure Control

  1. Sensor type : Normal open 3-way
  2. Operating temperature : -22~266°F (-30°C~130°C)
  3. Frequency : LR, 2ND, UD, OD, RED : 61.27Hz (at the ATF temp. -20°C above)

DCC : 30.64Hz, VFS : 600±20Hz

KM series : 35Hz

  1. Internal resistance : 2.7~3.4ohms (68°F or 20°C)
  2. Surge voltage : 56 V

Scheme 646

Scheme 646: Schematic Diagram

Scheme 647

Scheme 647: Signal Waveform

Scheme 648

Scheme 648: Monitor Scantool Data

Scheme 649

Scheme 649

Scheme 650

Scheme 650

Scheme 651

Scheme 651

Scheme 652

Scheme 652

Scheme 653

Scheme 653

Scheme 654

Scheme 654
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "PRESS CONTROL SOL. VALVE" parameter on the scantool
  4. Shift gear position "N" to "4TH GEAR".
  5. Does "PRESS CONTROL SOL DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION VEHICLE REPAIR»(ref-380250-S29915622152010121800000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-380250-S33083622602010121800000) " procedure

Solenoid Valve for Pressure Control

  1. Sensor type : Normal open 3-way
  2. Operating temperature : -22~266°F (-30°C~130°C)
  3. Frequency : LR, 2ND, UD, OD, RED : 61.27Hz (at the ATF temp. -20°C above)

DCC : 30.64Hz, VFS : 600±20Hz

KM series : 35Hz

  1. Internal resistance : 2.7~3.4ohms (68°F or 20°C)
  2. Surge voltage : 56 V

Scheme 655

Scheme 655: Schematic Diagram

Scheme 656

Scheme 656: Signal Waveform

Scheme 657

Scheme 657: Monitor Scantool Data

Scheme 658

Scheme 658

Scheme 659

Scheme 659

Scheme 660

Scheme 660

Scheme 661

Scheme 661

Scheme 662

Scheme 662

Scheme 663

Scheme 663
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "PRESS CONTROL SOL. VALVE" parameter on the scan tool
  4. Shift gear at each position.
  5. Does "PRESS CONTROL SOL DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION VEHICLE REPAIR»(ref-380250-S02674722602010121800000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-380250-S14032784382010121800000) " procedure

Solenoid Valve for Pressure Control

  1. Sensor type : Normal open 3-way
  2. Operating temperature : -22~266°F (-30°C~130°C)
  3. Frequency : LR, 2ND, UD, OD, RED : 61.27Hz (at the ATF temp. -20°C above)

DCC : 30.64Hz

KM series : 35Hz

  1. Internal resistance : 2.7~3.4ohms (68°F or 20°C)
  2. Surge voltage : 56 V

Scheme 664

Scheme 664: Schematic Diagram

Scheme 665

Scheme 665: Signal Waveform

Scheme 666

Scheme 666: Monitor Scantool Data

Scheme 667

Scheme 667

Scheme 668

Scheme 668

Scheme 669

Scheme 669

Scheme 670

Scheme 670

Scheme 671

Scheme 671

Scheme 672

Scheme 672
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "LR SOL. VALVE" parameter on the scantool
  4. Shift gear at each position.
  5. Does "LR SOLENOID DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION VEHICLE REPAIR»(ref-380250-S12629315972010121800000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-380250-S37329628782010121800000) " procedure

Solenoid Valve for Pressure Control

  1. Sensor type : Normal open 3-way
  2. Operating temperature : -22~266°F (-30°C~130°C)
  3. Frequency : LR, 2ND, UD, OD, RED : 61.27Hz (at the ATF temp. -20°C above)

DCC : 30.64Hz

KM series : 35Hz

  1. Internal resistance : 2.7~3.4ohms (68°F or 20°C)
  2. Surge voltage : 56 V

Scheme 673

Scheme 673: Schematic Diagram

Scheme 674

Scheme 674: Signal Waveform

Scheme 675

Scheme 675: Monitor Scantool Data

Scheme 676

Scheme 676

Scheme 677

Scheme 677

Scheme 678

Scheme 678

Scheme 679

Scheme 679

Scheme 680

Scheme 680
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "UD SOL. VALVE" parameter on the scantool
  4. Shift gear at each position.
  5. Does "UD SOLENOID DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION VEHICLE REPAIR»(ref-380250-S05624664132010121800000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-380250-S07086953572010121800000) " procedure

Solenoid Valve for Pressure Control

  1. Sensor type : Normal open 3-way
  2. Operating temperature : -22~266°F (-30°C~130°C)
  3. Frequency : LR, 2ND, UD, OD, RED : 61.27Hz (at the ATF temp. -20°C above)

DCC : 30.64Hz

KM series : 35Hz

  1. Internal resistance : 2.7~3.4ohms (68°F or 20°C)
  2. Surge voltage : 56 V

Scheme 681

Scheme 681: Schematic Diagram

Scheme 682

Scheme 682: Signal Waveform

Scheme 683

Scheme 683

Scheme 684

Scheme 684: Monitor Scantool Data

Scheme 685

Scheme 685

Scheme 686

Scheme 686

Scheme 687

Scheme 687

Scheme 688

Scheme 688

Scheme 689

Scheme 689

Scheme 690

Scheme 690
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "2nd SOL. VALVE" parameter on the scantool
  4. Shift gear at each position.
  5. Does "2nd SOLENOID DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-380250-S18128288952010121800000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-380250-S25469322012010121800000) " procedure

Solenoid Valve for Pressure Control

  1. Sensor type : Normal open 3-way
  2. Operating temperature : -22~266°F (-30°C~130°C)
  3. Frequency : LR, 2ND, UD, OD, RED : 61.27Hz (at the ATF temp. -20°C above)

DCC : 30.64Hz

KM series : 35Hz

  1. Internal resistance : 2.7~3.4ohms (68°F or 20°C)
  2. Surge voltage : 56 V

Scheme 691

Scheme 691: Schematic Diagram

Scheme 692

Scheme 692: Signal Waveform

Scheme 693

Scheme 693

Scheme 694

Scheme 694: Monitor Scantool Data

Scheme 695

Scheme 695

Scheme 696

Scheme 696

Scheme 697

Scheme 697

Scheme 698

Scheme 698

Scheme 699

Scheme 699

Scheme 700

Scheme 700
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "OD SOL. VALVE" parameter on the scantool
  4. Shift gear at each position.
  5. Does "OD SOLENOID DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION VEHICLE REPAIR»(ref-380250-S11886855102010121800000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-380250-S36685479982010121800000) " procedure

Solenoid Valve for Pressure Control

  1. Sensor type : Normal open 3-way
  2. Operating temperature : -22~266°F (-30°C~130°C)
  3. Frequency : LR, 2ND, UD, OD, RED : 61.27Hz (at the ATF temp. -20°C above)

DCC : 30.64Hz

KM series : 35Hz

  1. Internal resistance : 2.7~3.4ohms (68°F or 20°C)
  2. Surge voltage : 56 V

Scheme 701

Scheme 701: Schematic Diagram

Scheme 702

Scheme 702: Signal Waveform

Scheme 703

Scheme 703

Scheme 704

Scheme 704: Monitor Scantool Data

Scheme 705

Scheme 705

Scheme 706

Scheme 706

Scheme 707

Scheme 707

Scheme 708

Scheme 708

Scheme 709

Scheme 709

Scheme 710

Scheme 710
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "RED SOL. VALVE" parameter on the scantool
  4. Shift gear at each position.
  5. Is "RED SOLENOID DUTY" within specifications? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION VEHICLE REPAIR»(ref-380250-S24304627412010121800000) " procedure NO Go to " «W/HARNESS INSPECTION»(ref-380250-S28178943652010121800000) " procedure
