Esc (Electronic Stability Control): Specifications Kia Sedona II

Anti-Lock/traction Control 8 illustrations ~183 words

SPECIFICATION

DescriptionSpecificationRemark
Nominal supply voltage11.5-12.5 V
Supply voltage range8-16 V
Supply currentMax. 120 mAType. 75 mA
Reference Voltage Output2.464-2.536 VType. 2.5 V
Operating temperature range40-85 °C
Yaw-late sensorMeasurement range+w direction, left turnMin.100 °/sType. 111 °/S
W direction, right turnMin.100 °/sType. 111 °/S
Non-linearity1-1 %
Offset (within life, within operating temperature)3.75 °/S
Upper cut-off frequencyMin. 45 HzType. 60 Hz
Lateral G sensorMeasurement range+y direction, left turnMin.1.8 gType. 2 g
Y direction, right turnMin. -1.8 gType. 2 g
Non-linearity4-4 %
Offset (within life, within operating temperature)0.09-0.09 g
Upper cut-off frequencyMin. 20 HzType. 40 Hz

YAW-RATE & LATERAL G SENSOR SPECIFICATION

Scheme 85

Scheme 85: OUTPUT CHARACTERISTIC

Scheme 86

Scheme 86: CIRCUIT DIAGRAM (YAW-RATE & LATERAL G SENSOR)
DescriptionSpecification
Operating voltage8-16 V
Operating temperature40-85 °C
Current consumptionMax. 150 mA
Steering angle velocityMax. ±2000 °/sec
Connection delay timeT < 200 ms
Reverse voltage13.5 V
Measuring rangeAngle780 °-779 °
Angular velocity0- 1016 °/s
Nonlinearity angle2.5 °-+2.5 °
Hysteresis angle0 °-5 °
Rotational friction torque measuring10 °/s

SPECIFICATION

Scheme 87

Scheme 87: CIRCUIT DIAGRAM (STEERING WHEEL SPEED ANGLE SENSOR)

Scheme 88

Scheme 88: STEERING ANGLE SENSOR (SAS) CALIBRATION

Scheme 89

Scheme 89

Scheme 90

Scheme 90

Scheme 91

Scheme 91

Scheme 92

Scheme 92
  1. PURPOSE OF calibration On vehicle control, an ESC analyzes the intention of the driver. An ESC recognizes a steering angle which a driver rotates through the steering angle sensor. A steering angle sensor used in ESC adjusts 0° setting of steering wheel through K-line or CAN communication.
  2. STEERING ANGLE SENSOR (SAS) CALIBRATION METHOD Align the wheel to the straight line, (steering wheel < ± 5°) ex) Perform the wheel alignment first. Align the wheel to the straight line. A driver moves the vehicle to the front and back about 5 meters twice or three times. Connect Scan tool to the vehicle. Select Brake system. Select Steering angle sensor (SAS) calibration. Perform the Steering angle sensor (SAS) calibration. Perform the procedure continuously. The procedure is finished. Push the "ESC" key. Scanner OFF. Remove the scanner from the vehicle. Confirm the Steering angle sensor (SAS) calibration as driving the vehicle (turn left once, turn right once).
