Evaporative Emission Control System: Removal & Installation Kia Rio III

Installation

Installation is the reverse of removal.

Canister installation bolt/nut

19.6 ~ 29.4 N.m (2.0 ~ 3.0 kgf.m, 14.5 ~ 21.7 lb-ft)

Scheme 21

1. Remove the fuel pump. (Refer to " «FUEL PUMP»(ref-536090-S02005501242013031400000) ")
2. Remove the ORVR valve (A) after releasing hooks (B).

1. Install in the reverse order of removal.

Scheme 22

1. Remove the fuel pump. (Refer to " «FUEL PUMP»(ref-536090-S02005501242013031400000) ")
2. Remove the roll over valve (A) after releasing hooks (B).

1. Install in the reverse order of removal.

1. Install in the reverse order of removal.
