Steering System - General Information: Other Kia Rio III

Special Service Tools

Tool (Number and Name) Illustration Use 09568-34000 Crossmember support Supporting of the crossmember 09568-34000 Ball joint puller Remove the ball joint from the front axle 0956-11001 Steering wheel puller Remove the steering wheel

Scheme 1

Scheme 2

Scheme 3

1. Turn the steering wheel so that the front wheels can face straight ahead.
2. Measure the distance the steering wheel can be turned without moving the front wheels. Standard value: 30mm (1.1811 in.) or less
3. If the play exceeds standard value, inspect the steering column, shaft, and linkages.

Scheme 4

1. Position the vehicle on a level surface and place the steering wheel in the straight ahead position.
2. Attach a spring scale to the steering wheel. With the engine speed 900 ~ 1100rpm, pull the scale and read it as soon as the tires begin to turn. Standard value: 3.0kgf or less
3. If the measured value exceeds standard value, inspect the power steering gear box and MDPS system.
