Multifunction Switch: Diagnosis Kia Rio III

Lighting Switch Inspection

With the multifunction switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the multifunction switch.

Scheme 3

Scheme 4

Scheme 5

HS: Head lamp switch(Short inside)

Scheme 6

Scheme 7

Scheme 8

Wiper And Washer Switch Inspection

With the multifunction switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the multi-function switch.

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

1. Disconnect the negative (-) battery terminal.
2. Remove the steering wheel. (Refer to the " «STEERING COLUMN AND SHAFT»(ref-536086-S11460282932013031400000) ")
3. Remove the steering column upper (A) and lower (B) shrouds after removing the screw.
4. Disconnect the connector(A). Release the lock of wiper switch using tool without removing the steering wheel and the clock spring. Remove the wiper and washer switch.

Scheme 17

1. Disconnect the negative (-) battery terminal.
2. Remove the steering wheel. (Refer to the " «STEERING COLUMN AND SHAFT»(ref-536086-S11460282932013031400000) ")
3. Remove the steering column upper and lower shrouds after removing 3 screws.
4. Remove the clock spring. (Refer to the " «AIRBAG MODULE»(ref-536085) ")
5. Disconnect the lighting switch connector and wiper & washer switch connector. Remove the multifunction switch assembly (A) after loosening 2 mounting screws.

1. Install the multifunction switch.
2. Install the clock spring.
3. Install the steering column upper and lower shrouds.
4. Install the steering wheel. NOTE: Make sure the multifunction switch connectors are plugged in properly.
