[5 Door]

CAUTIONTake care not to scratch the door trim and other parts. Put on gloves to protect your hands.

Scheme 99

Scheme 99

Scheme 100

Scheme 100

Scheme 101

Scheme 101
  1. Using a screwdriver or remover, remove the rear door delta inner cover (A).
  2. After loosening the mounting screw, then remove the rear door inside handle housing (B).
  3. After loosening the mounting screws, then remove the rear door trim (A).
  4. Disconnect the power window connector (A).
  5. Installation is the reverse of removal. NOTE: Make sure connectors are connected properly and each rod is connected securely. Make sure the door lock and opens properly. Replace any damaged clips.

[4 Door]

CAUTIONBe careful not to scratch the door trim and other parts. Put on gloves to protect your hands.

Scheme 102

Scheme 102

Scheme 103

Scheme 103
  1. After loosening the mounting screw, then remove the rear door inside handle housing (B).
  2. After loosening the mounting screws, then remove the rear door trim (A).
  3. Disconnect the power window switch connector (A).
  4. Installation is the reverse of removal. NOTE: Make sure connectors are connected properly and each rod is connected securely. Make sure the door lock and opens properly. Replace any damaged clips.

Scheme 104

Scheme 104: Inside Handle Replacement

Scheme 105

Scheme 105
  1. Remove the following items: Rear door trim.
  2. After loosening the mounting screw, then remove the rear door inside handle (A).
  3. Disconnect the rear door inside handle cable (A).
  4. Installation is the reverse of removal. NOTE: Replace any damaged clips. Make sure the door lock and opens properly.

Scheme 106

Scheme 106: [5 Door]

Scheme 107

Scheme 107

Scheme 108

Scheme 108

Scheme 109

Scheme 109

Scheme 110

Scheme 110

Scheme 111

Scheme 111

Scheme 112

Scheme 112

Scheme 113

Scheme 113

Scheme 114

Scheme 114
  1. Remove the following items: Rear door trim.
  2. After loosening the mounting screw, then remove the rear door inside handle (A).
  3. Disconnect the rear door inside handle cable (A).
  4. Disconnect the rear door speaker connector (A).
  5. After loosening the mounting screws, then remove the rear door trim seal mounting bracket (B).
  6. Remove the rear door trim seal (A). NOTE: Replace any damaged door trim seal.
  7. Loosen the rear door delta molding mounting screws.
  8. Remove the rear door delta molding (A).
  9. Loosen the rear door channel mounting nuts. Tightening torque: 3.9 ~ 5.9 N.m (0.4 ~ 0.6 kgf.m, 2.9 ~ 4.3 lb-ft)
  10. Remove the rear door belt inside weatherstrip (A).
  11. Carefully move the glass (A) until you can see the bolts, then loosen them. Separate the glass from the glass run and carefully pull the glass out through the window slot. CAUTION: Take care not to drop to glass and scratch the glass surface. Tightening torque: 7.8 ~ 11.8 N.m (0.8 ~ 1.2 kgf.m, 5.8 ~ 8.7 lb-ft)
  12. Installation is the reverse of removal. NOTE: Roll the glass up down to see if it move freely without binding. Adjust the position of the glass as necessary.

Scheme 115

Scheme 115: [4 Door]

Scheme 116

Scheme 116

Scheme 117

Scheme 117

Scheme 118

Scheme 118

Scheme 119

Scheme 119

Scheme 120

Scheme 120

Scheme 121

Scheme 121

Scheme 122

Scheme 122

Scheme 123

Scheme 123

Scheme 124

Scheme 124
  1. Remove the rear door trim.
  2. After loosening the mounting screw, then remove the rear door inside handle (A).
  3. Disconnect the rear door inside handle cable (A).
  4. Disconnect the rear door speaker connector (A).
  5. After loosening the mounting screws, then remove the rear door trim seal mounting bracket (B).
  6. Remove the rear door trim seal (A). NOTE: Replace any damaged door trim seal.
  7. After loosening the mounting screw, then remove the rear door inside handle (A).
  8. After loosening the mounting screws, then remove the rear door belt outside weatherstrip (A).
  9. Loosen the rear door window run & fixed glass (A) mounting screw and bolt.
  10. Remove the rear door window run & fixed glass (A).
  11. Loosen the rear door channel mounting nuts. Tightening torque: 3.9 ~ 5.9 N.m (0.4 ~ 0.6 kgf.m, 2.9 ~ 4.3 lb-ft)
  12. Carefully move the glass (A) until you can see the bolts, then loosen them. Separate the glass from the glass run and carefully pull the glass out through the window slot. CAUTION: Take care not to drop to glass and scratch the glass surface. Tightening torque: 7.8 ~ 11.8 N.m (0.8 ~ 1.2 kgf.m, 5.8 ~ 8.7 lb-ft)
  13. Installation is the reverse of removal. NOTE: Roll the glass up down to see if it move freely without binding. Adjust the position of the glass as necessary. Make sure connectors are connected properly and each rod is connected securely. Make sure the door lock and opens properly. Replace any damaged clips.

Scheme 125

Scheme 125: Speaker Replacement
  1. Remove the following items: Rear door trim.
  2. Disconnect the speaker connector (B).
  3. After loosening the mounting screws, then remove the rear door speaker (A).
  4. Installation is the reverse of removal. NOTE: Use sheet metal screws to secure the speaker. Make sure connectors are connected properly and each rod is connected securely. Make sure the door locks/unlocks and opens/closes properly. Replace any damaged clips.

Scheme 126

Scheme 126: Door Power Window Regulator Assembly Replacement

Scheme 127

Scheme 127

Scheme 128

Scheme 128
  1. Remove the following items: Rear door trim Rear door trim seal Rear door glass
  2. Loosen the rear door power window regulator mounting nuts.
  3. Disconnect the rear door power window motor connector (A). Tightening torque: 3.9 ~ 5.9 N.m (0.4 ~ 0.6 kgf.m, 2.9 ~ 4.3 lb-ft)
  4. Remove the rear door power window regulator assembly (A).
  5. After loosening the mounting nuts, then remove the rear door power window motor (A).
  6. Installation is the reverse of removal. NOTE: Grease should be applied to areas where there is rotational parts and springs. Roll the glass up and down to see if it move freely without binding.

Scheme 129

Scheme 129: Outside Handle Replacement

Scheme 130

Scheme 130
  1. Remove the hole plug (B).
  2. After loosening the mounting bolt, then remove the outside handle cover (A). Tightening torque: 7.8 ~ 10.8 N.m (0.8 ~ 1.1 kgf.m, 5.8 ~ 8.0 lb-ft)
  3. Remove the outside handle (A) by sliding it rearward.
  4. Installation is the reverse of removal. NOTE: Make sure the door locks/unlocks and opens/closes properly. Make sure the door locks and opens properly.

Scheme 131

Scheme 131: Door Latch Replacement

Scheme 132

Scheme 132

Scheme 133

Scheme 133

Scheme 134

Scheme 134

Scheme 135

Scheme 135

Scheme 136

Scheme 136
  1. Remove the following items: Rear door trim Rear door trim seal
  2. Loosen the rear door channel mounting nuts. Tightening torque: 3.9 ~ 5.9 N.m (0.4 ~ 0.6 kgf.m, 2.9 ~ 4.3 lb-ft)
  3. Remove the rear door channel (A).
  4. Disconnect the outside handle rod (A).
  5. Loosen the rear door latch (A) mounting screws. Tightening torque: 7.8 ~ 10.8 N.m (0.8 ~ 1.1kgf.m, 5.8 ~ 8.0 lb-ft)
  6. Remove the rear door latch assembly (A).
  7. Disconnect the rear door latch connector (A).
  8. Installation is the reverse of removal. NOTE: Make sure the connector is connected properly. Make sure the door locks/unlocks and opens/closes properly. Replace any damaged clips.

Scheme 137

Scheme 137: Door Side Weatherstrip Replacement

Scheme 138

Scheme 138
  1. Detach the clips, then remove the rear door side weatherstrip (A). [5 Door] [4 Door]
  2. Installation is the reverse the removal. NOTE: Replace any damaged clips.

When To Initialize The Motor

  1. After initial vehicle assembly.
  2. If the initial value is erased or damaged because of short power electric discharge during operation.
  3. After using the manual handle.

Scheme 139

Scheme 139: Operating The Sunroof Emergency Handle
  1. Use the sunroof emergency handle to close or open the sunroof manually if the sunroof cannot be closed electronically due to motor or controller electrical malfunction.
  2. Operating method. Remove the roof trim. Push the emergency handle up into the hexagonal drive (A) of the sunroof motor. You must push hard enough to disengage the motor clutch; otherwise the emergency handle will slip due to incomplete fit in the motor. Carefully turn the emergency handle clockwise to close the sunroof. After closing the sunroof, wiggle the handle back and forth as you remove the tool from the motor, to ensure the motor clutch reengages. A 5mm hex socket may be used in place of the emergency handle, with a "Speeder" type handle. CAUTION: Do not use power tools to operate the sunroof. Damage to the components may occur.
