Interior: Other Kia Rio III

Gauges & Instrument Panels 31 illustrations ~578 words

[M/T]

CAUTIONA plastic trim tool is recommended, but if prying with a screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Put on gloves to protect your hands.

Scheme 69

Scheme 69
Scheme 69

Scheme 70

Scheme 70
Scheme 70

Scheme 71

Scheme 71
Scheme 71

Scheme 72

Scheme 72
Scheme 72

Scheme 73

Scheme 73
Scheme 73
  1. Using a screwdriver or remover, remove the gear boots (A).
  2. Using a screwdriver or remover, remove the console upper cover (A).
  3. Using a screwdriver or remover, remove the parking brake cover (A).
  4. Remove the floor console pad (A).
  5. After loosening the mounting bolts and clips, then remove the floor console assembly (A).
  6. Installation is the reverse of removal. NOTE: Make sure the connector are connected in properly. Replace any damage clips.

[A/T]

CAUTIONA plastic trim tool is recommended, but if prying with a screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Put on gloves to protect your hands.

Scheme 74

Scheme 74
Scheme 74

Scheme 75

Scheme 75
Scheme 75

Scheme 76

Scheme 76
Scheme 76

Scheme 77

Scheme 77
Scheme 77

Scheme 78

Scheme 78
Scheme 78

Scheme 79

Scheme 79
Scheme 79
  1. Using a screwdriver or remover, remove the gear boots (B) and gear knob (A).
  2. Using a screwdriver or remover, remove the console upper cover (A).
  3. Disconnect the connectors (A).
  4. Using a screwdriver or remover, remove the parking brake cover (A).
  5. Remove the floor console pad (A).
  6. After loosening the mounting bolts, screws, clips, then remove the floor console assembly (A).
  7. Installation is the reverse of removal. NOTE: Make sure the connectors are connected in properly. Replace any damaged clips.

Scheme 80

Scheme 80: Components (1)
Scheme 80: Components (1)

Scheme 81

Scheme 81: Components (2)
Scheme 81: Components (2)

[5 Door]

CAUTIONPut on gloves to protect your hands. Use a plastic panel removal tool to remove interior trim pieces to without marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 82

Scheme 82
Scheme 82

Scheme 83

Scheme 83
Scheme 83

Scheme 84

Scheme 84
Scheme 84

Scheme 85

Scheme 85
Scheme 85

Scheme 86

Scheme 86
Scheme 86

Scheme 87

Scheme 87
Scheme 87

Scheme 88

Scheme 88
Scheme 88
  1. Remove the following items: Rear seat assembly (Refer to the " «REAR SEAT»(ref-536123-S09518006422013031400000) ")
  2. After loosening the mounting screws, then remove the rear door scuff trim (A).
  3. Using a screwdriver or remover, remove the rear transverse trim (A).
  4. After loosening the mounting bolt, then remove the rear seat belt lower anchor (A). Tightening torque: 39.2 ~ 53.9 N.m (4.0 ~ 5.5 kgf.m, 28.8 ~ 39.8 lb-ft)
  5. After loosening the mounting blots, then remove the rear seat bracket (A).
  6. Using a screwdriver or remover, remove the lamp (A).
  7. Disconnect the lamp connector (B).
  8. After loosening the mounting screws, then remove the luggage side trim (A).
  9. Remove the rear seat belt upper anchor cover (B).
  10. Using a screwdriver or remover, remove the rear pillar trim (A).
  11. Installation is the reverse of removal. NOTE: Make sure the connectors are connected in properly. Replace any damage clips.

[4 Door]

CAUTIONPut on gloves to protect your hands. Use a plastic panel removal tool to remove interior trim pieces to without marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 89

Scheme 89
Scheme 89
  1. Using a screwdriver or remover, remove the rear pillar trim (A).
  2. Installation is the reverse of removal. NOTE: Replace any damage clips.
CAUTIONPut on gloves to protect your hands. Use a plastic panel removal tool to remove interior trim pieces to without marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 90

Scheme 90
Scheme 90
  1. Remove the rear seat. (Refer to the " «REAR SEAT»(ref-536123-S09518006422013031400000) ")
  2. Remove the rear door scuff trim.
  3. Remove the rear transverse trim.
  4. After loosening the mounting screws, then remove the luggage side trim.
  5. Installation is the reverse of removal. NOTE: Replace any damage clips.
CAUTIONPut on gloves to protect your hands. Use a plastic panel removal tool to remove interior trim pieces to without marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 91

Scheme 91
Scheme 91

Scheme 92

Scheme 92
Scheme 92

Scheme 93

Scheme 93
Scheme 93

Scheme 94

Scheme 94
Scheme 94

Scheme 95

Scheme 95
Scheme 95

Scheme 96

Scheme 96
Scheme 96

Scheme 97

Scheme 97
Scheme 97

Scheme 98

Scheme 98
Scheme 98

Scheme 99

Scheme 99
Scheme 99
  1. Remove the rear seat assembly. (Refer to the " «REAR SEAT»(ref-536123-S09518006422013031400000) ")
  2. Using a screwdriver or remover, remove the rear pillar trim (A).
  3. After loosening the mounting screws, then remove the rear door scuff trim (A).
  4. After loosening the mounting bolt, then remove the rear seat belt lower anchor (A). Tightening torque: 39.2 ~ 53.9 N.m (4.0 ~ 5.5 kgf.m, 28.8 ~ 39.8 lb-ft)
  5. After loosening the mounting blots, then remove the rear seat folding bracket (A).
  6. After loosening the mounting clips and screws, then remove the luggage partition trim (A).
  7. After loosening the mounting clips and screw, then remove the rear wheel housing trim (A).
  8. Disconnect the high mounted stop lamp connector (A).
  9. Remove the rear seat belt upper anchor cover (A).
  10. Remove the rear package tray trim (A).
  11. Installation is the reverse of removal. NOTE: Make sure the connectors are connected in properly. Replace any damage clips.
