Cylinder Head Assembly: Removal & Installation Kia Rio III

Removal

Engine removal is not required for this procedure.

Note. Mark all wiring and hoses to avoid misconnection.

Scheme 157

Scheme 158

Scheme 159

Scheme 160

Scheme 161

Scheme 162

Scheme 163

Scheme 164

Scheme 165

Scheme 166

Scheme 167

Scheme 168

Scheme 169

Scheme 170

Scheme 171

Scheme 172

Scheme 173

Scheme 174

Scheme 175

Scheme 176

Scheme 177

Scheme 178

Scheme 179

Scheme 180

Scheme 181

Scheme 182

Scheme 183

Scheme 184

Scheme 185

Scheme 186

Scheme 187

Scheme 188

1. Remove the engine cover.
2. Disconnect the battery terminals (A).
3. Remove the air cleaner assembly. Remove the air duct (A) Disconnect the breather hose (B) and the air intake hose (C) Remove the air cleaner assembly (D)
4. Remove the battery (A) after removing the mounting bracket.
5. Disconnect the ECM connectors (A) and then remove the ECM (B) and battery tray (C).
6. Remove the RH front wheel.
7. Remove the under covers (A).
8. Loosen the drain plug, and drain the engine coolant. Remove the radiator cap to help drain the coolant faster. (Refer to «COOLING SYSTEM»(ref-536074) in this group)
9. Disconnect the radiator upper hose (A) and lower hose (B).
10. Disconnect the wiring connectors and harness clamps, and remove the wiring and protectors from the cylinder head and intake manifold. The A/C compressor switch connector (A), the alternator connector (B) and the cable from the alternator "B" terminal (C) The intake OCV (Oil control valve) connector (A) and the exhaust OCV (Oil control valve) connector (B) The ignition coil connectors (A), the injector extension connector (B), the VIS (Variable intake system) connector (C) and the PCSV (Purge control solenoid valve) connector (D) The FPCV (Fuel pressure control valve) connector (A), the intake CMPS (Camshaft position sensor) connector (B) and the exhaust CMPS (Camshaft position sensor) connector (C) Disconnect the oxygen sensor connectors (A) and the condenser connector (B) The ECTS (Engine coolant temperature sensor) connector (A) and the ground line (B) The ETC (Electronic throttle control) connector (A) and the MAPS (Manifold absolute pressure sensor) & IATS (Intake air temperature sensor) connector (B)
11. Disconnect the brake booster vacuum hose (A) and heater hose (B).
12. Disconnect the fuel hose (A), the PCV (Positive crankcase ventilation) hose (B) and the PCSV (Purge control solenoid valve) hose (C).
13. Remove the vacuum pipe assembly (A).
14. Remove the high pressure pipe (A). (Refer to «DELIVERY PIPE»(ref-536090-S33337824992013031400000) .
15. Remove the high pressure fuel pump (A) and the roller tappet (B). (Refer to «HIGH PRESSURE FUEL PUMP»(ref-536090-S17368312702013031400000) .
16. Remove the ignition coils (A).
17. Remove the exhaust OCV (Oil control valve) (B).
18. Remove the cylinder head cover (A) with gaskets (B).
19. Remove the exhaust OCV (Oil control valve) adapter (A).
20. Remove the timing chain. (Refer to «TIMING SYSTEM»(ref-536072) in this group)
21. Remove the exhaust manifold assembly. (Refer to «INTAKE AND EXHAUST SYSTEM»(ref-536078) in this group)
22. Remove the intake manifold module assembly. (Refer to «INTAKE AND EXHAUST SYSTEM»(ref-536078) in this group)
23. Remove the intake continuous variable valve timing (CVVT) assembly (A) and exhaust continuous variable valve timing (CVVT) assembly (B). NOTE: When removing the continuous variable valve timing (CVVT) assembly bolt, prevent the camshaft from rotating by using a wrench at position (A).
24. Remove the camshaft bearing caps (A) with the order below.
25. Remove the camshafts (A).
26. Remove the injector & rail assembly (A).
27. Remove the water temperature control assembly (B) after disconnecting the throttle body cooling hose (A).
28. Remove the heater pipe (A).
29. Remove the intake OCV (Oil Control Valve) (A).
30. Remove the cylinder head bolts, then remove the cylinder head. Uniformly loosen and remove the 10 cylinder head bolts, in several passes, in the sequence shown. CAUTION: Head warpage or cracking could result from removing bolts in an incorrect order. Lift the cylinder head from the cylinder block and put the cylinder head on wooden blocks. CAUTION: Be careful not to damage the contact surfaces of the cylinder head and cylinder block.

Installation

Note. Thoroughly clean all parts to be assembled. Always use a new cylinder head and manifold gasket. Always use a new cylinder head bolt. The cylinder head gasket is a metal gasket. Take care not to bend it. Rotate the crankshaft, set the No. 1 piston at TDC.

Scheme 189

Scheme 190

Scheme 191

Scheme 192

Scheme 193

Scheme 194

Scheme 195

Scheme 196

Scheme 197

Scheme 198

Scheme 199

Scheme 200

Scheme 201

Scheme 202

Scheme 203

Scheme 204

Scheme 205

Scheme 206

Scheme 207

Scheme 208

Scheme 209

Scheme 210

Scheme 211

Scheme 212

Scheme 213

Scheme 214

Scheme 215

Scheme 216

Scheme 217

Scheme 218

Scheme 219

Scheme 220

Scheme 221

Scheme 222

Scheme 223

Scheme 224

Scheme 225

Scheme 226

Scheme 227

Scheme 228

Scheme 229

1. Install the cylinder head assembly. Before installing, remove the hardened sealant from the cylinder block and cylinder head surface. Before installing the cylinder head gasket, apply sealant on the upper surface of the cylinder block and reassemble the gasket within five minutes. NOTE: Refer to the illustration for applying sealant. Width: 2.0 ~ 3.0mm(0.0787~0.1181in.) Position: 1.0 ~ 1.5mm(0.0394~0.0591in.) Specification: TB 1217H or LOCTITE 5900H After installing the cylinder head gasket on the cylinder block, apply sealant on the upper surface of the cylinder head gasket and reassemble in five minutes.
2. Place the cylinder head carefully not to damage the gasket.
3. Install the cylinder head bolts with washers. Tighten the 10 cylinder head bolts, in several passes, in the sequence shown. Tightening torque: 29.4Nm (3.0kgf.m, 21.7lb-ft) + 90° + 90° CAUTION: Always use new cylinder head bolts.
4. Install the oil control valve (OCV) (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) CAUTION: Do not reuse the OCV when dropped. Keep the OCV filter clean. Do not hold the OCV sleeve (A) during servicing. When the OCV is installed on the engine, do not move the engine with holding the OCV yoke.
5. Install the heater pipe (A). Tightening torque M6 bolt and nuts: 9.8 ~ 11.8N.m (1.0 ~ 1.2kgf.m, 7.2 ~ 8.7lb-ft) M8 bolts: 18.6 ~ 23.5N.m (1.9 ~ 2.4kgf.m, 13.7 ~ 17.4lb-ft)
6. Install the water temperature control assembly (A) after connecting the throttle body cooling hose (A). Tightening torque: 9.8 ~ 11.8N.m (1.0 ~ 1.2kgf.m, 7.2 ~ 8.7lb-ft)
7. Install the injector&rail assembly (A). Tightening torque: 18.6 ~ 23.5N.m (1.9 ~ 2.4kgf.m, 13.7 ~ 17.4lb-ft)
8. Install the intake and exhaust manifold. (Refer to «INTAKE AND EXHAUST SYSTEM»(ref-536078) in this group)
9. Install the camshafts (A). Before installing, apply engine oil on journals. CAUTION: Do not make oil flow down to the front side of the cylinder head. After installing, check the valve clearance.
10. Install the camshaft bearing caps with the order below. Tightening torque 1st step M6 bolt: 5.9 N.m (0.6 kgf.m, 4.3 lb-ft) M8 bolt: 9.8 N.m (1.0 kgf.m, 7.2 lb-ft) 2nd step M6 bolts: 11.8 ~ 13.7N.m (1.2 ~ 1.4kgf.m, 8.7 ~ 10.1lb-ft) M8 bolts: 18.6 ~ 22.6N.m (1.9 ~ 2.3kgf.m, 13.7 ~ 16.6lb-ft)
11. Install the intake CVVT assembly (A) and exhaust CVVT assembly (B). Tightening torque: 63.7 ~ 73.5N.m (6.5 ~ 7.5kgf.m, 47.0 ~ 54.2lb-ft) NOTE: When installing the CVVT assembly bolt, prevent the camshaft from rotating by using a wrench at position (A).
12. Install the timing chain. (Refer to «TIMING SYSTEM»(ref-536072) in this group)
13. Install the OCV (Oil Control Valve) adapter (A). Tightening torque: 9.8 ~ 11.8N.m (1.0 ~ 1.2kgf.m, 7.2 ~ 8.7lb-ft) CAUTION: Keep the OCV adapter clean. Make sure the O-rings on the front bearing cap are installed.
14. Install the cylinder head cover (A) with a new gasket (B). CAUTION: Do not reuse the disassembled gasket.
15. Tighten the cylinder head cover bolts (A) with the order and steps. Tightening torque: 1st step: 3.9 ~ 5.9 N.m (0.4 ~ 0.6 kgf.m, 2.9 ~ 4.3 lb-ft) 2nd step: 7.8 ~ 9.8 N.m (0.8 ~ 1.0 kgf.m, 5.8 ~ 7.2 lb-ft)
16. Install the exhaust OCV (Oil control valve) (A). Tightening torque: 9.8 ~ 11.8N.m (1.0 ~ 1.2kgf.m, 7.2 ~ 8.7lb-ft) CAUTION: Do not reuse the OCV when dropped. Keep the OCV filter clean. Do not hold the OCV sleeve (A) during servicing. When the OCV is installed on the engine, do not move the engine with holding the OCV yoke.
17. Install the ignition coils (A). Tightening torque: 9.8 ~ 11.8N.m (1.0 ~ 1.2kgf.m, 7.2 ~ 8.7lb-ft)
18. Install the high pressure fuel pump (A) and the roller tappet (B). (Refer to «HIGH PRESSURE FUEL PUMP»(ref-536090-S17368312702013031400000) . Tightening torque: 12.7 ~ 14.7N.m (1.3 ~ 1.5kgf.m, 9.4 ~ 10.8lb-ft) CAUTION: Before installing the high pressure fuel pump, position the roller tappet in the lowest position (BDC) by rotating the crankshaft. Otherwise the installation bolts may be broken because of tension of the pump spring. NOTE: Do not use already used bolt again. NOTE: When tightening the installation bolts of the high pressure fuel pump, tighten in turn the bolts in small step (0.5 turns) after tightening them with hand-screwed torque. CAUTION: Note that internal damage may occur when the component is dropped. In this case, use it after inspecting. CAUTION: Apply engine oil to the O-ring (A) of the high pressure fuel pump, the roller tappet (B), and the protrusion (C). Also apply engine oil to the groove where the protrusion is installed.
19. Install the high pressure pipe (A). (Refer to «DELIVERY PIPE»(ref-536090-S33337824992013031400000) . Tightening torque: 25.5 ~ 31.4N.m (2.6 ~ 3.2kgf.m, 18.8 ~ 23.1lb-ft) CAUTION: Do not reuse the high pressure pipe.
20. Install the vacuum pipe assembly (A). Tightening torque: 9.8 ~ 11.8N.m (1.0 ~ 1.2kgf.m, 7.2 ~ 8.7lb-ft)
21. Connect the fuel hose (A), the PCV (Positive crankcase ventilation) hose (B) and the PCSV (Purge control solenoid valve) hose (C).
22. Connect the brake booster vacuum hose (A) and heater hose (B). NOTE: Install the heater hoses as shown illustrations.
23. Connect the wiring connectors and harness clamps, and remove the wiring and protectors from the cylinder head and intake manifold. The A/C compressor switch connector (A), the alternator connector (B) and the cable from the alternator "B" terminal (C) Tightening torque: 9.8 ~ 11.8N.m (1.0 ~ 1.2kgf.m, 7.2 ~ 8.7lb-ft) The intake OCV (Oil control valve) connector (A) and the exhaust OCV (Oil control valve) connector (B) The ignition coil connectors (A), the injector extension connector (B), the VIS (Variable intake system) connector (C) and the PCSV (Purge control solenoid valve) connector (D) The FPCV (Fuel pressure control valve) connector (A), the intake CMPS (Camshaft position sensor) connector (B) and the exhaust CMPS (Camshaft position sensor) connector (C) The oxygen sensor connectors (A) and the condenser connector (B). The ECTS (Engine coolant temperature sensor) connector (A) and the ground line The ETC (Electronic throttle control) connector (A) and the MAPS (Manifold absolute pressure sensor)&IATS (Intake air temperature sensor) connector (B)
24. Connect the radiator upper hose (A) and lower hose (B). NOTE: Install the radiator hoses as shown illustrations.
25. Install the under covers (A). Tightening torque: 6.9 ~ 10.8 N.m (0.7 ~ 1.1 kgf.m, 5.1 ~ 8.0 lb-ft)
26. Install the battery tray (C). Tightening torque: 8.8 ~ 13.7 N.m (0.9 ~ 1.4 kgf.m, 6.5 ~ 10.1 lb-ft)
27. Install the ECM (B) and then connect the ECM connectors (A). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft)
28. Install the battery (A) after removing the mounting bracket. Tightening torque: 8.8 ~ 13.7 N.m (0.9 ~ 1.4 kgf.m, 6.5 ~ 10.1 lb-ft)
29. Install the RH front wheel.
30. Install the air cleaner assembly. Install the air cleaner assembly (D) and the air intake hose (C). Tightening torque Hose clamp bolt: 2.9 ~ 4.9N.m (0.3 ~ 0.5kgf.m, 2.2 ~ 3.6lb-ft) Air cleaner assembly bolts: 7.8 ~ 9.8N.m (0.8 ~ 1.0kgf.m, 5.8 ~ 7.2lb-ft) Connect the breather hose (B). Install the air duct (A). NOTE: Install the air intake hose while the plate of the hose clamp must be in line with the stopper of the hose. Install the air intake hose while the groove of hose must be matched to the protrusion of the throttle body.
31. Connect the battery negative terminals (A). Tightening torque (+) terminal: 7.8 ~ 9.8N.m (0.8 ~ 1.0kgf.m, 5.8 ~ 7.2lb-ft) (-) terminal (without battery sensor): 7.8 ~ 9.8N.m (0.8 ~ 1.0kgf.m, 5.8 ~ 7.2lb-ft) (-) terminal (with battery sensor): 4.0 ~ 6.0N.m (0.4 ~ 0.6kgf.m, 3.0 ~ 4.4lb-ft)
32. Install the engine cover. CAUTION: Install the engine cover. NOTE: Perform the following: Adjust a shift cable. Refill engine with engine oil. Refill a transaxle with fluid. Refill a radiator and a reservoir tank with engine coolant. Clean battery posts and cable terminals and assemble. Inspect for fuel leakage. After assemble the fuel line, turn on the ignition switch (do not operate the starter) so that the fuel pump runs for approximately two seconds and fuel line pressurizes. Repeat this operation two or three times, then check for fuel leakage at any point in the fuel line. Bleed air from the cooling system. Start engine and let it run until it warms up. (until the radiator fan operates 3 or 4 times.) Turn Off the engine. Check the level in the radiator, add coolant if needed. This will allow trapped air to be removed from the cooling system. Put radiator cap on tightly, then run the engine again and check for leaks.
