Crash Pad Lower Panel Replacement
| CAUTION | A plastic trim tool is recommended, but if prying with a screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Take care not to bend or scratch the trim and panels. Put on gloves to protect your hands. |
Scheme 9
Scheme 10
Scheme 11
Scheme 12
- Using a screwdriver or remover, remove the crash pad side cover (A).
- Using a screwdriver or remover, remove the fuse box cover (A).
- After loosening the mounting screws and bolt, then remove the crash pad lower panel (A).
- Disconnect the connectors (A) and diagnosis connector (B).
- Installation is the reverse of removal. NOTE: Make sure the connectors are connected in properly. Replace any damage clips.
