Audio assembly Replacement Kia Rio III

Interior: Removal & Installation 4 illustrations

Audio assembly Replacement

CAUTION

A plastic trim tool is recommended, but if prying with a screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Take care not to bend or scratch the trim and panels. Put on gloves to protect your hands.

Scheme 13

Scheme 13

Scheme 13

Scheme 14

Scheme 14

Scheme 14

Scheme 15

Scheme 15

Scheme 15

Scheme 16

Scheme 16

Scheme 16

Using a screwdriver or remover, remove the center fascia panel (A).
Disconnect the start/stop button connector (A) and hazard switch connector (B).
After loosening the mounting screws, then remove the audio assembly (A).
Disconnect the connectors (A).
Installation is the reverse of removal. NOTE: Make sure the connectors are connected in properly. Replace any damaged clips.
