Head Lamp Leveling Device: Removal & Installation Kia Rio III

Removal

1. Disconnect the negative (-) battery terminal.
2. Remove the head lamp assembly (Refer to the «HEAD LAMP»(ref-536133-S26438767662013031400000) .
3. Remove the head lamp leveling actuator by turning the adjusting gear in the hole using the adjusting wheel or screw driver.

Installation

1. Install the head lamp leveling actuator by turning the adjusting gear.
2. Install the head lamp assembly.
3. Adjust the head lamp in accordance with the head lamp aiming instructions.

Scheme 8

1. Disconnect the negative (-) battery terminal.
2. Remove the crash pad lower panel. (Refer to the " «INTERIOR (CRASH PAD)»(ref-536097-S26973898002013031400000) ")
3. Remove the crash pad side switch assembly.
4. Disconnect the head lamp leveling switch connector from lower crash pad switch.
5. Remove the head lamp leveling switch.
6. The installation is the reverse of removal.
