General Description
PAS is a Rear Parking Assistant System. It has a supersonic sensor which radiates supersonic to rear side of the vehicle to detect supersonic reflected from an obstacle. It consist of 4 sensor and calculates distances between vehicle and obstacle if it detects reflected supersonic. BCM receive the signal of calculated distances by LIN communication. It warns being obstacle to drivers through buzzer or displaying on cluster according to distance from obstacle. Warning level is divided into 3 step. (warning level rises progressively according to distance from obstacle)
DTC Description
This code reports an error in LIN line. The purpose is to verify the status of BCM, Sensor and Wire when error is detected at RPAS of left side sensor.
RPAS is a Rear Parking Assistant System. It has a supersonic sensor which radiates supersonic to rear side of the vehicle to detect supersonic reflected from an obstacle. It consist of 4 sensor and calculates distances between vehicle and obstacle if it detects reflected supersonic. BCM receive the signal of calculated distances by LIN communication. It warns being obstacle to drivers through buzzer or displaying on cluster according to distance from obstacle. Warning level is divided into 3 step. (warning level rises progressively according to distance from obstacle)
This code reports an error in LIN line. The purpose is to verify the status of BCM, Sensor and Wire when error is detected at RPAS of Rear Center Left Sensor.
RPAS is a Rear Parking Assistant System. It has a supersonic sensor which radiates supersonic to rear side of the vehicle to detect supersonic reflected from an obstacle. It consist of 4 sensor and calculates distances between vehicle and obstacle if it detects reflected supersonic. BCM receive the signal of calculated distances by LIN communication. It warns being obstacle to drivers through buzzer or displaying on cluster according to distance from obstacle. Warning level is divided into 3 step. (warning level rises progressively according to distance from obstacle)
This code reports an error in LIN line. The purpose is to verify the status of BCM, Sensor and Wire when error is detected at RPAS of Rear Center Right Sensor.
RPAS is a Rear Parking Assistant System. It has a supersonic sensor which radiates supersonic to rear side of the vehicle to detect supersonic reflected from an obstacle. It consist of 4 sensor and calculates distances between vehicle and obstacle if it detects reflected supersonic. BCM receive the signal of calculated distances by LIN communication. It warns being obstacle to drivers through buzzer or displaying on cluster according to distance from obstacle. Warning level is divided into 3 step. (warning level rises progressively according to distance from obstacle)
This code reports an error in LIN line. The purpose is to verify the status of BCM, Sensor and Wire when error is detected at RPAS of Right side sensor.
This is DTC which is related with communication error between BCM and other units.
Body CAN communication Control Units: BCM(Body Control Module), CLU(Cluster), SMK(Smart Key).
*1 CAN (Controller Area Network): CAN is serial bus communication type which links not only communication system but also control units each other.
*2 LIN (Local Interconnect Network): LIN is serial communication type which is used in electrical control system. (This is less expensive.)
Scheme 9
| Type | Condition | Remark |
|---|---|---|
| 1 | CANH Circuit Open | B1602 is presented when IC detects one of errors among 7 types under normal communication condition. According to operation condition, some of module which are connected to CAN line may not detect B1602. Also, B1603 can be detected together. |
| 2 | CANL Circuit Open | |
| 3 | CANH Circuit Short to Power | |
| 4 | CANL Circuit Short to Power | |
| 5 | CANH Circuit Short to Ground | |
| 6 | CANL Circuit Short to Ground | |
| 7 | CANH and CANL Short to each other |
DTC DESCRIPTION
This is DTC which is related with communication error between BCM and other units.
Body CAN communication Control Units: BCM(Body Control Module), CLU(Cluster), SMK(Smart Key).
*1 CAN (Controller Area Network): CAN is serial bus communication type which links not only communication system but also control units each other.
*2 LIN (Local Interconnect Network): LIN is serial communication type which is used in electrical control system. (This is less expensive.)
Scheme 10
This is DTC which is related with communication error between BCM and other units.
(Control Units: BCM(Body Control Module), CLU(Cluster), SMK(Smart Key).
Case1: After short between CAN Low Line and High Line, short to ground together.
Case2: After short between CAN Low Line and High Line, short to power together.
This code is occurred when It is not possible to transmit data by CAN Line in those way of Software and Hardware. But, It is possible to receive data by CAN Line.
This code reports BUS OFF status when data transmit error count number is over 255. The purpose is to verify the status of CAN controller and CAN communication line when error is detected.
According to operation condition, some of module which are connected to CAN line may not detect B1603.
Also, B1602 coincides with B1603 at all times.
| CAUTION | Difference between CAN ERROR and CAN BUS ERROR CAN Error: MIL On, CAN Bus Error: No MIL |
