Motor Driven Power Steering Diagnosis: Specifications Kia Rio III

Electronic Steering 6 illustrations ~349 words

Specification

Bat. VoltageIG Key ONENG. ON
Approx. 11.8 [V]~12.5 [V]Approx. 12.5 [V] ~ 14.5 [V]

Scheme 64

Scheme 64: Diagnostic Circuit Diagram

Scheme 65

Scheme 65: Monitor Scantool Data
  1. Connect scantool to Data Link Connector(DLC).
  2. Start engine and turn the headlight and the heatwire on.
  3. Monitor the "SUPPLY VOLTAGE" parameter on the scantool.
  4. Maintaining ENGINE at 2, 500 RPM (idle) over 2 minutes. Specification: Approx. 12.5V~14.5V
  5. Is parameter within specifications? YES Fault is intermittent and caused either by poor contact in connectors or wiring harness, or it has been repaired and EPS CM memory is not cleared yet. Thoroughly check all connectors (and connections) for looseness, bending, corrosion, contamination, deterioration, and/or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536168-S34235011132013031400000) " procedure. NO Go to " «W/HARNESS INSPECTION»(ref-536168-S34552147252013031400000) " procedure.
Bat. VoltageIG Key ONENG. ON
Approx. 11.8 [V]~12.5 [V]Approx. 12.5 [V] ~ 14.5 [V]

Scheme 66

Scheme 66: Diagnostic Circuit Diagram

Scheme 67

Scheme 67: Monitor Scantool Data
  1. Connect scantool to Data Link Connector(DLC).
  2. Start engine and turn the headlight and the heatwire on.
  3. Monitor the "SUPPLY VOLTAGE" parameter on the scantool.
  4. Maintaining ENGINE at 2, 500 RPM (idle) over 2 minutes. BATTERY VOLTAGE SPECIFICATION Bat. Voltage IG Key ON ENG. ON Approx. 11.8V~12.5V Approx. 12.5V~14.5V
  5. Is parameter within specifications? YES Fault is intermittent and caused either by poor contact in connectors or wiring harness, or it has been repaired and EPS CM memory is not cleared yet. Thoroughly check all connectors (and connections) for looseness, bending, corrosion, contamination, deterioration, and/or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536168-S20196733022013031400000) " procedure. NO Go to " «W/HARNESS INSPECTION»(ref-536168-S12885232542013031400000) " procedure.
Bat. VoltageIG Key ONENG. ON
Approx. 11.8 [V] ~ 12.5 [V]Approx. 12.5 [V] ~ 14.5 [V]

Scheme 68

Scheme 68: Diagnostic Circuit Diagram

Scheme 69

Scheme 69: Monitor Scantool Data
  1. Connect scantool to Data Link Connector(DLC).
  2. Start engine and turn the headlight and the heatwire on.
  3. Monitor the "SUPPLY VOLTAGE" parameter on the scantool.
  4. Maintaining ENGINE at 2, 500 RPM (idle) over 2 minutes. Specification
  5. Is parameter within specifications? YES Fault is intermittent and caused either by poor contact in connectors or wiring harness, or it has been repaired and EPS CM memory is not cleared yet. Thoroughly check all connectors (and connections) for looseness, bending, corrosion, contamination, deterioration, and/or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536168-S31548813112013031400000) " procedure. NO Go to " «W/HARNESS INSPECTION»(ref-536168-S34308472412013031400000) " procedure.
