Electric Power Steering: Overview Kia Rio III

Electronic Steering 15 illustrations ~628 words

Scheme 1

Scheme 1: Components
Scheme 1: Components

Scheme 2

Scheme 2: MDPS Circuit Diagram
Scheme 2: MDPS Circuit Diagram

Scheme 3

Scheme 3: Harness Connector
Scheme 3: Harness Connector
ConnectorPin noPin nameDescriptionSpecification
TAS sensor signal 8P connector A1VTS2SENT2 Supply voltage
2VTS2PWM Supply voltage
3PWMTAS PWM signal
4GNDVTS2 GND
5VTS1SENT1 Supply voltage
6SENT1TAS SENT1 signal
7SENT2TAS SENT2 signal
8GNDVTS1 GND
Vehicle signal 8P connector B1IGN1Ignition signalECU operating voltage: 90V ~ 160V
2NCNbt connected
3NCNbt connected
4NCNbt connected
5NCNbt connected
6NCNbt connected
7CAN HCAN BUS High lineReference to HMC ES96480-00
8CAN LCAN BUS Low lineReference to HMC ES96480-00
Battery 2P connector C1BAT +Battery positiveECU operating voltage: 9.0V ~16.0V Peak < I < 65A @ DC12V, MDPS Fu operation Leakage < I < 0.5mA @ DC12V, MDPS OFF
2BATChassis ground
Motor 2P connector D1MOT +Motor wire
2MOTMotor wire

Description

  1. EPS (Electronic Power Steering, Column assist type) system uses an electric motor to assist the steering force and it is an engine operation independent steering system.
  2. EPS control module controls the motor operation according to information received from the each sensor and CAN (Controller Area Network).
  3. Resulting in a more precise and timely control of steering assist than conventional engine-driven hydraulic systems. Components (Steering Angle Sensor, Torque Sensor, Fail-safe relay, etc.) of the EPS system are located inside the steering column & EPS unit assembly must not be disassemble to inspect or replace them.
Trouble factorCheck itemTrouble symptomExplanationNote
Drop, impact, and overloadMotorAbnormal noiseVisible or invisible damage can occur. The steering wheel could pull to one side by using the dropped parts. Precise parts of motor/ECU are sensitive to vibration and impact.- Overload can cause unexpected damageDo not use the impacted EPS.- Do not overload each parts.
ECUCircuit damage-Wrong welding point-Broken PCB Damaged precise parts
Torque sensorInsufficient steering effortOverload to INPUT shaft can cause malfunction of the torque sensorDo not impact the connecting parts (When inserting and torquing) Use the specified tool to remove the steering wheel. (Do not hammer on it) Do not use the impacted EPS
Angle sensorInsufficient steering effort (Uneven between LH and RH)Do not use the impacted EPS
Pull/DentHarnessMalfunction impossible power operation-Malfunction of EPSDisconnection between harness connecting portion and harnessDo not overload the harness
Abnormal storage temperatureMotor/ECUAbnormal steering effort by improper operation of the motor/ECUWaterproof at the normal condition Even a little moisture can cause malfunction of the precise parts of the motor/ECUKeep the normal temperature and proper moisture, while storaging Avoid drowning

NOTE WITH REGARD TO DIAGNOSIS

  1. Do not impact the electronic parts, if they are dropped or impacted, replace them with new ones.
  2. Avoid heat and moisture to the electronic parts.
  3. Do not contact the connect terminal to avoid deformation and static electricity.
  4. Do not impact the motor and torque sensor parts, if they are dropped or impacted, replace them with new ones.
  5. The connector should be disconnected or connected with IG OFF.

Scheme 4

Scheme 4: Replacement
Scheme 4: Replacement

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13
  1. Disconnect the battery negative cable from the battery and then wait for at least 30 seconds.
  2. Turn the steering wheel so that the front wheels can face straight ahead.
  3. Remove the airbag module. (Refer to «DRIVER AIRBAG (DAB) MODULE AND CLOCK SPRING»(ref-536085-S31332743872013031400000)
  4. Loosen the lock nut (A), disconnect the connector (B) and then remove the steering wheel by using SST(0956-11001). Tightening torque: 39.2 ~ 44.1N.m(4.0 ~ 4.5kgf.m, 28.9 ~ 32.5lb-ft) CAUTION: Do not hammer on the steering wheel to remove it; it may damage the steering column.
  5. Loosen the screw and then remove the steering column upper (A) and lower shroud (B).
  6. Disconnect the connector (B) and then remove the clock spring (A). CAUTION: When assembling set the center position by setting the marks between the clock spring and the cover into line. Make an array the mark () by turning the clock spring clockwise to the stop and then 2.0 revolutions counterclockwise.
  7. Disconnect the connector (A).
  8. Loosen the screw and then remove the multifunction switches (A).
  9. Remove the crash pad side cover, Fuse box cover and lower crash pad. (Refer to «CRASH PAD»(ref-536097-S26973898002013031400000)
  10. Loosen the bolt (A) and then disconnect the universal joint assembly from the pinion of the steering gear box. Tightening torque: 32.4 ~ 37.3N.m(3.3 ~ 3.8kgf.m, 23.9 ~ 27.5lb-ft) CAUTION: Lock the steering wheel in the straight ahead position to prevent the damage of the clock spring inner cable when you handle the steering wheel. Must be replaced with new bolts when assembling. (SEAL-LOCK has been processed) SEAL-LOCK Specifications: MS721-39 "TYPE-D" Product: ND industries 1193S
  11. Disconnect all connectors connected the steering column & EPS unit assembly.
  12. Remove the steering column & EPS unit assembly by loosening the mounting bolt (B) and nuts (A). Tightening torque: Nut: 14.7 ~ 17.7N.m(1.5 ~ 1.8kgf.m, 10.8 ~ 13.0lb-ft) Bolt: 44.1 ~ 49.0N.m(4.5 ~ 5.0kgf.m, 32.5 ~ 36.2lb-ft)
  13. Installation is the reverse of the removal. CAUTION: If MDPS type, you must be EPS type recognition (Refer to «Repair procedures»(ref-536086-S21157043652013031400000) ST group - E.P.S/repair procedures)
  14. Compensate the steering angle sensor after replacing the steering column.

Scheme 14

Scheme 14: Key lock assembly
Scheme 14: Key lock assembly
  1. Make a groove on the head of special bolts (A) with a chisel.
  2. Loosen the special bolt using a screw driver and then remove the key lock assembly from the steering column assembly.
  3. Reassembly is the reverse of the disassembly.

Scheme 15

Scheme 15: Universal joint assembly
Scheme 15: Universal joint assembly
  1. Loosen the bolt (A) and then disconnect the universal joint assembly from the steering column assembly. Tightening torque: 27.5 ~ 29.4N.m(2.8 ~ 3.0kgf.m, 20.3 ~ 21.7lb-ft)
  2. Reassembly is the reverse of the disassembly. CAUTION: Do not disassemble the EPS module from the column shaft.
