Smart Key Code Saving (Button) Diagnosis: Diagnosis Kia Rio III

DTC INDEX

DTC INDEX

Scheme 206

DTC Detecting Condition

Scheme 207

Scheme 208

Scheme 209

1. IG KEY "ON" & Engine "OFF".
2. Erase DTC after connecting GDS.
3. Check Smart key status if DTC is retrieved.
4. Is the Smart key ECM/PCM learnt status? YES Fault is intermittent caused by poor contact in Smart key ECM/PCM and/or ECM/PCM's connector or was repaired and Smart key ECM/PCM memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536166-S02271175522013031400000) " procedure. NO Go to " «COMPONENT INSPECTION»(ref-536166-S22355407442013031400000) " procedure.

Scheme 210

1. Check Smart Key ECM/PCM Insepction IG KEY "ON" & Engine "OFF". Neutralize smart key ECM/PCM with GDS. Perform key teaching procedure for smart key ECM/PCM with GDS. CAUTION: Pin code must be prepared to Neutralize Smart Key ECM/PCM and to perform key teaching procedure Is the neutralization of Smart Key ECM/PCM, Engine ECM/PCM and key teaching normal? YES Fault is intermittent caused by poor contact in Smart Key ECM/PCM and/or ECM/PCM's connector or was repaired and Smart key ECM/PCM memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536166-S02271175522013031400000) " procedure. NO Substitute with a known-good Smart Key ECM/PCM and check for proper operation. If the problem is corrected, replace Smart Key ECM/PCM and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536166-S02271175522013031400000) " procedure. NOTE: PIN code is programmed in Smart key ECM/PCM, Transponder, ESCL. If the Smart key ECM/PCM is not registered with PIN, key teaching process is not proceeded. Registering PIN is available after Smart Key ECM/PCM is neutralized. Neutralization of Engine ECM/PCM is available with GDS (Registering PIN code) If the virgin engine ECM/PCM is installed on vehicle, Engine ECM/PCM is automatically programmed PIN code by Smart Key ECM/PCM. Registering PIN code is only possible for virgin or neutralized status. All Learning procedure is able to do with a scan tool in the vehicle's ignition key off state. Smart Key ECM/PCM Learning Before learning procedure for ESCL, Smart Key ECM/PCM should be registered PIN code first. In case of replacing Smart Key ECM/PCM, All of the keys should be newly registered again. In case that Smart Key ECM/PCM receives 3 times with wrong PIN, It is not allowed for neutralization and Key Teaching for 1 hour. If the battery is discharged during neutralization or Teaching, Timer will start again from beginning. Therefore, it is avoidable to wait for 1 hour. ESCL Learning It is O.K for registering ESCL just one time. And, it is available for ESCL to neutralize and re-teach with same PIN code.

Scheme 211

Scheme 212

Scheme 213

1. IG KEY "ON" & Engine "OFF".
2. Erase DTC after connecting GDS.
3. Check Smart Key ECM/PCM status parameter if DTC is retrieved.
4. Is the smart Key ECM/PCM learnt? YES Fault is intermittent caused by poor contact in Smart key ECM/PCM and or ECM/PCM's connector or was repaired and Smart key ECM/PCM memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536166-S37315560602013031400000) " procedure. NO Go to " «WIRE HARNESS INSPECTION»(ref-536166-S20128066232013031400000) " procedure.

Terminal and Connector Inspection

1. Many malfunctions in the electrical system are caused by poor harness and terminal connections. Faults can also be caused by interference from other electrical systems, and mechanical or chemical damage.
2. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage.
3. Has a problem been found? YES Repair as necessary and go to " «VERIFICATION VEHICLE REPAIR»(ref-536166-S37315560602013031400000) " procedure. NO Go to " «SIGNAL CIRCUIT INSPECTION»(ref-536166-S20792508072013031400000) " procedure.

Scheme 214

Scheme 215

1. IG KEY OFF.
2. Disconnect Engine ECM/PCM connector.
3. IG KEY "ON".
4. Measure voltage between signal terminal of ECM/PCM harness connector and chassis ground. Specification: About 12V
5. Is the measured voltage within specification? YES Go to " «COMPONENT INSPECTION»(ref-536166-S03191701152013031400000) " procedure. NO Check open or short to signal circuit and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536166-S37315560602013031400000) " procedure.

Scheme 216

1. Check Smart Key ECM/PCM Insepction IG KEY "ON" & Engine "OFF". Neutralize smart key ECM/PCM with GDS. Perform key teaching procedure for smart key ECM/PCM with GDS. CAUTION: Pin code must be prepared to Neutralize Smart Key ECM/PCM and to perform key teaching procedure Is the neutralization of Smart Key ECM/PCM, Engine ECM/PCM and key teaching normal? YES Fault is intermittent caused by poor contact in Smart Key ECM/PCM and/or ECM/PCM's connector or was repaired and Smart key ECM/PCM memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536166-S37315560602013031400000) " procedure. NO Substitute with a known-good Smart Key ECM/PCM and check for proper operation. If the problem is corrected, replace Smart Key ECM/PCM and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536166-S37315560602013031400000) " procedure. NOTE: PIN code is programmed in Smart key ECM/PCM, Transponder, ESCL. If the Smart key ECM/PCM is not registered with PIN, key teaching process is not proceeded. Registering PIN is available after Smart Key ECM/PCM is neutralized. Neutralization of Engine ECM/PCM is available with GDS (Registering PIN code) If the virgin engine ECM/PCM is installed on vehicle, Engine ECM/PCM is automatically programmed PIN code by Smart Key ECM/PCM. Registering PIN code is only possible for virgin or neutralized status. All Learning procedure is able to do with a scan tool in the vehicle's ignition key off state. Smart Key ECM/PCM Learning Before learning procedure for ESCL, Smart Key ECM/PCM should be registered PIN code first. In case of replacing Smart Key ECM/PCM, All of the keys should be newly registered again. In case that Smart Key ECM/PCM receives 3 times with wrong PIN, It is not allowed for neutralization and Key Teaching for 1 hour. If the battery is discharged during neutralization or Teaching, Timer will start again from beginning. Therefore, it is avoidable to wait for 1 hour. ESCL Learning It is O.K for registering ESCL just one time. And, it is available for ESCL to neutralize and re-teach with same PIN code.

Scheme 217

Scheme 218

Scheme 219

Scheme 220

Scheme 221

1. IG KEY "ON" & Engine "OFF".
2. Erase DTC after connecting GDS.
3. Check Smart Key ECM/PCM status parameter if DTC is retrieved.
4. Is the neutralization of Smart Key ECM/PCM, Engine ECM/PCM and key teaching normal? YES Neutralize the ECM/PCM after erasing the DTC with GDS. Check that system is normal after checking the DTC again. (If the DTC is set again, replace ECM/PCM) Wait for more than 1 min. with IG ON so that smart key ECM/PCM register PIN into Engine ECM/PCM automatically. NO Perform key teaching procedure after replacing ECM/PCM and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536166-S40640816012013031400000) " Procedure. NOTE: PIN code is programmed in Smart key ECM/PCM, Transponder, ESCL. If the Smart key ECM/PCM is not registered with PIN, key teaching process is not proceeded. Registering PIN is available after Smart Key ECM/PCM is neutralized. Neutralization of Engine ECM/PCM is available with GDS (Registering PIN code) If the virgin engine ECM/PCM is installed on vehicle, Engine ECM/PCM is automatically programmed PIN code by Smart Key ECM/PCM. Registering PIN code is only possible for virgin or neutralized status. All Learning procedure is able to do with a scan tool in the vehicle's ignition key off state. Smart Key ECM/PCM Learning Before learning procedure for ESCL, Smart Key ECM/PCM should be registered PIN code first. In case of replacing Smart Key ECM/PCM, All of the keys should be newly registered again. In case that Smart Key ECM/PCM receives 3 times with wrong PIN, It is not allowed for neutralization and Key Teaching for 1 hour. If the battery is discharged during neutralization or Teaching, Timer will start again from beginning. Therefore, it is avoidable to wait for 1 hour. ESCL Learning It is O.K for registering ESCL just one time. And, it is available for ESCL to neutralize and re-teach with same PIN code.

Scheme 222

Scheme 223

Scheme 224

1. IG KEY "ON" & Engine "OFF".
2. Erase DTC after connecting GDS.
3. Check Smart Key ECM/PCM status parameter if DTC is retrieved.
4. Is the smart Key ECM/PCM learnt? YES Fault is intermittent caused by poor contact in Smart key ECM/PCM and/or ECM/PCM's connector or was repaired and Smart key ECM/PCM memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536166-S10615897992013031400000) " procedure. NO Go to " «COMPONENT INSPECTION»(ref-536166-S31503006722013031400000) " procedure.

Scheme 225

1. Check Smart Key ECM/PCM Insepction IG KEY "ON" & Engine "OFF". Neutralize smart key ECM/PCM with GDS. Perform key teaching procedure for smart key ECM/PCM with GDS. CAUTION: Pin code must be prepared to Neutralize Smart Key ECM/PCM and to perform key teaching procedure Is the neutralization of Smart Key ECM/PCM, Engine ECM/PCM and key teaching normal? YES Fault is intermittent caused by poor contact in Smart Key ECM/PCM and/or ECM/PCM's connector or was repaired and Smart key ECM/PCM memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536166-S10615897992013031400000) " procedure. NO Substitute with a known-good Smart Key ECM/PCM and check for proper operation. If the problem is corrected, replace Smart Key ECM/PCM and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536166-S10615897992013031400000) " procedure. NOTE: PIN code is programmed in Smart key ECM/PCM, Transponder, ESCL. If the Smart key ECM/PCM is not registered with PIN, key teaching process is not proceeded. Registering PIN is available after Smart Key ECM/PCM is neutralized. Neutralization of Engine ECM/PCM is available with GDS (Registering PIN code) If the virgin engine ECM/PCM is installed on vehicle, Engine ECM/PCM is automatically programmed PIN code by Smart Key ECM/PCM. Registering PIN code is only possible for virgin or neutralized status. All Learning procedure is able to do with a scan tool in the vehicle's ignition key off state. Smart Key ECM/PCM Learning Before learning procedure for ESCL, Smart Key ECM/PCM should be registered PIN code first. In case of replacing Smart Key ECM/PCM, All of the keys should be newly registered again. In case that Smart Key ECM/PCM receives 3 times with wrong PIN, It is not allowed for neutralization and Key Teaching for 1 hour. If the battery is discharged during neutralization or Teaching, Timer will start again from beginning. Therefore, it is avoidable to wait for 1 hour. ESCL Learning It is O.K for registering ESCL just one time. And, it is available for ESCL to neutralize and re-teach with same PIN code.

Scheme 226

Scheme 227

Scheme 228

Scheme 229

1. IG KEY "ON" & Engine "OFF".
2. Erase DTC after connecting GDS.
3. Check Smart Key ECM/PCM status parameter if DTC is retrieved.
4. Is the neutralization of Smart Key ECM/PCM, Engine ECM/PCM and key teaching normal? YES Neutralize the ECM/PCM after erasing the DTC with GDS. Check that system is normal after checking the DTC again. (If the DTC is set again, replace ECM/PCM) Wait for more than 1 min. with IG ON so that smart key ECM/PCM register PIN into Engine ECM/PCM automatically. NO Perform key teaching procedure after replacing ECM/PCM and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-536166-S39521614002013031400000) " Procedure. NOTE: PIN code is programmed in Smart key ECM/PCM, Transponder, ESCL. If the Smart key ECM/PCM is not registered with PIN, key teaching process is not proceeded. Registering PIN is available after Smart Key ECM/PCM is neutralized. Neutralization of Engine ECM/PCM is available with GDS (Registering PIN code) If the virgin engine ECM/PCM is installed on vehicle, Engine ECM/PCM is automatically programmed PIN code by Smart Key ECM/PCM. Registering PIN code is only possible for virgin or neutralized status. All Learning procedure is able to do with a scan tool in the vehicle's ignition key off state. Smart Key ECM/PCM Learning Before learning procedure for ESCL, Smart Key ECM/PCM should be registered PIN code first. In case of replacing Smart Key ECM/PCM, All of the keys should be newly registered again. In case that Smart Key ECM/PCM receives 3 times with wrong PIN, It is not allowed for neutralization and Key Teaching for 1 hour. If the battery is discharged during neutralization or Teaching, Timer will start again from beginning. Therefore, it is avoidable to wait for 1 hour. ESCL Learning It is O.K for registering ESCL just one time. And, it is available for ESCL to neutralize and re-teach with same PIN code.
