Scheme 1
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
- Disconnect the negative (-) terminal (A) from the battery.
- Remove the bolts (A) in the illustration, and then remove the driver's airbag module (B). NOTE: For the vehicles not equipped with SRS airbag, remove the horn cover assembly.
- Remove the connector (A) and steering wheel lock nut (B).
- After aligning the marks on the steering shaft and wheel, remove the steering wheel using the special tool (09561-11002). NOTE: Do not hammer on the steering wheel to remove it: it may damage the steering column.
- Remove the steering column upper and lower shrouds after remaining the three bolts (A).
- Remove the lower crash pad (A) after loosening the four bolts in the illustration.
- Remove the bracket (A) by removing the four bolts (B).
- Remove the connectors of the multifunction switch (A).
- Remove the multifunction switch assembly (A).
- Remove the five bolts connecting the steering column shaft (A) and the universal joint (B) as shown in the illustration. CAUTION: Keep the neutral-range to prevent the damage of the clock spring inner cable when you handle the steering wheel.
Scheme 12
Scheme 13
- If it is necessary to remove the key lock assembly (A), use a punch to make a groove on the head of the special bolt (B), and then use a screwdriver to remove the key lock assembly mounting bracket (C).
- Disassemble the key lock assembly (A) from the steering column and shaft assembly (B).
- Reassembly is reverse of disassembly.
Scheme 14
Scheme 15
- Remove the bolt (A) connecting the universal joint assembly (B) and the steering column and shaft assembly (C).
- Remove the universal joint assembly (A) from the steering column and shaft assembly (B).
- Reassembly is reverse of disassembly.
