SPECIFICATION
| Items | Specifications |
|---|---|
| Rated voltage | DC 12 V |
| Operating temperature range | 30°C ~ +80°C (-22 ~ +176°F) |
| Rated load | |
| Dimmer & passing switch | High : 120W (Lamp load) Low : 110W (Lamp load) Passing : 120W (Lamp load) |
| Lighting switch | Lighting : 21W (Lamp load) |
| Turn signal & lane change switch | 69W (Lamp load) |
| Wiper & mist switch | Low, High : 5.0A (Motor load) Intermittent : 0.07±0.05A (Relay load) Lock : Max. 25A (Motor load) Mist: 5A (Motor load) |
| Washer switch | 4.0A (Motor load) |
| Rear wiper & washer switch (5doors) | Rear wiper : 3.5A (Motor load) Rear washer : 5A (Motor load) |
ITEM SPECIFICATION
Scheme 1
Scheme 2
Scheme 3
Scheme 4
- Disconnect the negative (-) battery terminal.
- Remove the steering column upper and lower shrouds (A) after removing 3 screws.
- Remove the light switch by pushing the lock pin (B) after disconnecting the connector (A).
- Remove the wiper switch by pushing the lock pin (B) after disconnecting the connector (A).
- Installation is the reverse of removal.
