INSPECTION
Check for continuity between the terminals.
Scheme 22
Scheme 23
- There should be continuity between No1 and No. 4 terminals when power and ground are connected to No. 2 and No. 3 terminals.
- There should be no continuity between No. 1 and No. 4 terminals when power is disconnected.
- If the blower motor voltage is not operated well, substitute with a known-good blower relay and check for proper operation.
- If the problem is corrected, replace the blower relay.
Scheme 24
Scheme 25
Scheme 26
- Measure terminal-to-terminal resistance of the blower resistor.
- If measured resistance is not within specification, the blower resistor must be replaced. (After removing the resistor)
Scheme 27
- Disconnect the negative (-) battery terminal.
- Disconnect the blower resistor connector (A) at the connecting part blower unit.
- Remove the blower resistor after loosening the mounting screws.
- Installation is the reverse order of removal.
