Airbag Modules & Clock Spring: Removal & Installation Kia Rio II рестайлинг

INSTALLATION

1. Disconnect the negative (-) cable from battery and wait for at least three minutes.
2. Remove ignition key from the vehicle.
3. Place a Passenger Airbag (PAB) on the crash pad and tighten the Passenger Airbag (PAB) mounting nuts. Tightening Torque : 0.4 ~ 0.7 kgf.m (3.9 ~ 6.9 N.m, 2.9 ~ 5.1 lb.ft)
4. Install the crash pad. (Refer to «CRASH PAD»(ref-378954-S04244826872010113000000) )
5. Tighten the PAB mounting bolts. Tightening Torque : 0.9 ~ 1.4 kgf.m (8.8 ~ 13.7 N.m, 6.5 ~ 10.1 lb.ft)
6. Connect the Passenger Airbag (PAB) harness connector to the SRS main harness connector.
7. Reinstall the glove box. (Refer to «INTERIOR»(ref-378954) )
8. Reconnect the battery negative cable.
9. After installing the Passenger Airbag (PAB), confirm proper system operation: Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off.

Note. Do not open the lid of the side airbag cover. Use a new mounting nuts when you replace a side airbag. Make sure that the seat-back cover is installed properly. Improper installation may prevent the proper deployment.

Scheme 35

1. Disconnect the battery negative cable and wait for at least three minutes.
2. Remove the ignition key from the vehicle.
3. Place a Side Airbag (SAB) on the seat-back frame and tighten the side airbag mounting nuts. Tightening torque : 0.5 ~ 0.7 kgf.m (4.9 ~ 69 Nm, 3.6 ~ 5.1 lb.ft)
4. Install the new seat-back cover. (Refer to «FRONT SEAT»(ref-378957-S28438456782010113000000) )
5. Install the seat assembly, then connect the Side Airbag (SAB) harness connector.
6. Recline and slide the front seat forward fully, make sure the harness wires are not pinched or interfering with other parts.
7. Reconnect the battery negative cable.
8. After installing the Side Airbag (SAB), confirm proper system operation: Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off.

1. Disconnect the negative (-) cable from battery and wait for at least three minutes.
2. Remove the ignition key from the vehicle.
3. Install a Curtain Airbag (CAB) on the mounting bracket. Tightening Torque (CAB Mounting Bolt) : 0.5 ~ 0.7 kgf.m (4.9 ~ 6.9 Nm, 3.6 ~ 5.1 lb.ft) CAUTION: Never twist the airbag module when installing it. If the module is twisted, airbag module may operate abnormally.
4. Install the inflator on the bracket.
5. Connect the CAB connector.
6. Reconnect the battery negative cable.
7. After installing the Curtain Airbag (CAB), confirm proper system operation: Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off.
