Airbag Modules & Clock Spring: Overview Kia Rio II рестайлинг

DESCRIPTION

Driver Airbag (DAB) is installed in steering wheel and electrically connected to SRSCM via clockspring. It protects the driver from danger by deploying a bag when frontal crash occurs. The SRSCM determines deployment of Driver Airbag (DAB).

Scheme 20

Scheme 21

Scheme 22

Scheme 23

1. Disconnect the battery negative cable and wait at least three minutes before beginning work.
2. Remove the three airbag module mounting bolts.
3. Disconnect the horn connector (A).
4. Release the connector locking pin (B), then disconnect the driver airbag module connector (C). CAUTION: The removed airbag module should be stored in a clean, dry place with the pad cover face up.
5. Remove the steering wheel and steering wheel column cover. (Refer to «REPAIR PROCEDURES»(ref-378919-S37349973052010113000000) )
6. Disconnect the clock spring and horn connector, then remove the clock spring.

Scheme 24

1. Disconnect the negative (-) cable from battery and wait for at least three minutes.
2. Remove the ignition key from the vehicle.
3. Connect the clock spring harness connector and horn harness connector to the clock spring.
4. Set the clock spring on neutral position and after turning the front wheels to the straight-ahead position, install the clock spring.
5. Install the steering wheel column cover and the steering wheel. (Refer to «REPAIR PROCEDURES»(ref-378919-S37349973052010113000000) )
6. Connect the Driver Airbag (DAB) module connector and horn connector, then install the Driver Airbag (DAB) module on the steering wheel.
7. Secure the Driver Airbag (DAB) with the new mounting bolts. Tightening Torque (DAB Mounting Bolt) : 0.8 ~ 1.1 kgf.m (7.9 ~ 10.8 Nm, 5.8 ~ 8.0 lb.ft)
8. Connect the battery negative cable.
9. After installing the airbag, confirm proper system operation: Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off. Make sure horn button works.

The passenger Airbag (PAB) is installed inside the crash pad and protects the front passenger in the event of a frontal crash. The SRSCM determines if and when to deploy the PAB.

Scheme 25

Scheme 26

Scheme 27

1. Disconnect the battery negative cable and wait for at least three minutes before beginning work.
2. Remove the glove box. (Refer to «INTERIOR»(ref-378954) )
3. Disconnect the PAB connector and remove the PAB mounting bolts.
4. Remove the crash pad. (Refer to «CRASH PAD»(ref-378954-S04244826872010113000000) )
5. Remove the mounting nuts from the crash pad. Then remove the passenger airbag. CAUTION: The removed airbag module should be stored in a clean, dry place with the pad cover face up.

The two Side Airbags (SAB) are installed inside the driver and passenger seat and protects the driver and front passenger from danger when side crash occurs. The SRSCM determines deployment of side airbag by using Side Impact Sensor (SIS) signal.

Scheme 28

Scheme 29

1. Disconnect the battery negative cable and wait at least 3 minutes before beginning work.
2. Remove the front seat assembly. (Refer to «FRONT SEAT»(/kia/rio/ii-2009-2011/remont/seats/#seat-power-seat) )
3. Remove the seat-back cover. (Refer to «FRONT SEAT»(/kia/rio/ii-2009-2011/remont/seats/#seat-power-seat) )
4. Loosen the SAB mounting nuts and remove the SAB module. CAUTION: The removed airbag module should be stored in a clean, dry place with the pad cover face up.

Curtain airbags are installed inside the headliner (LH and RH) and protect the driver and passenger from danger when side crash occurs. The SRSCM determines deployment of curtain airbag by using side impact sensor (SIS) signal.

Scheme 30

Scheme 31

Scheme 32

1. Disconnect the battery negative cable and wait for at of least 3 minutes before beginning work.
2. Remove the following parts. (Refer to «INTERIOR TRIM»(ref-378954-S04273294922010113000000) ) Interior trim Headlining
3. Disconnect the Curtain Airbag harness connector.
4. After loosening the mounting bolts, remove the curtain airbag.
