Power Windows Kia Rio II

Windows 16 illustrations ~319 words

Scheme 38

Scheme 38: COMPONENT LOCATION

Scheme 39

Scheme 39: FRONT POWER WINDOW MOTOR

Scheme 40

Scheme 40
  1. Remove the front door trim panel. (Refer to «INTERIOR»(ref-269624) )
  2. Disconnect the connector from the motor.
  3. Connect the motor terminals directly to battery voltage (12V) and check that the motor operates smoothly. Next, reverse the polarity and check that the motor operates smoothly in the reverse direction. If the operation is abnormal, replace the motor.

Scheme 41

Scheme 41: REAR POWER WINDOW MOTOR

Scheme 42

Scheme 42
  1. Remove the rear door trim panel. (Refer to «INTERIOR»(ref-269624) )
  2. Disconnect the 2P connector from the motor.
  3. Connect the motor terminals directly to battery voltage (12V) and check that the motor operates smoothly. Next, reverse the polarity and check that the motor operates smoothly in the reverse direction. If the operation is abnormal, replace the motor.

Scheme 43

Scheme 43: CIRCUIT DIAGRAM

Scheme 44

Scheme 44: POWER WINDOW MAIN SWITCH

Scheme 45

Scheme 45
  1. Disconnect the negative (-) battery terminal.
  2. Remove the front door trim panel. (Refer to «INTERIOR»(ref-269624) )
  3. Disconnect the 14P connector from the switch.
  4. Check for continuity between the terminals in each switch position according to the table. If the continuity condition is not normal, replace the switch.

Scheme 46

Scheme 46: POWER WINDOW LOCK SWITCH

Scheme 47

Scheme 47: ASSIST/REAR POWER WINDOW SWITCH

Scheme 48

Scheme 48
  1. Disconnect the negative (-) battery terminal.
  2. Remove the door trim panel. (Refer to «INTERIOR»(ref-269624) )
  3. Disconnect the 7P connector from the switch.
  4. Check for continuity between the terminals in each switch position according to the table. If the continuity condition is not normal, replace the switch.

Scheme 49

Scheme 49: INSPECTION

Scheme 50

Scheme 50
  1. Disconnect the negative (-) battery terminal.
  2. Remove the power window relay from the junction box.
  3. Check for continuity between the terminals.
  4. There should be continuity between the No.1 and No.4 terminals when power and ground are connected to the No.2 and No.3 terminals.
  5. There should be no continuity between the No.1 and No.4 terminals when power is disconnected.

Scheme 51

Scheme 51: TROUBLESHOOTING

Scheme 52

Scheme 52

Scheme 53

Scheme 53
  1. No windows operate from the main switch on the driver door.
  2. Driver side window does not operate.
  3. Assist side window does not operate.
