Power Windows - Optima: Overview Kia Optima III рестайлинг

Scheme 45

Operation Time Limiter

Maximal operation time of power window motor is limited to 15 sec (EEPROM programmable).

Scheme 46

Scheme 47

1. Remove the front door trim panel. Refer to FRONT DOOR .
2. Disconnect the connector from the motor.
3. Connect the motor terminals No. 2 and No. 3 directly to battery voltage (12V) and check that the motor operates smoothly. If the operation is abnormal, replace the motor.

Scheme 48

Scheme 49

1. 4. Connect the motor terminals directly to battery voltage (12V) and check that the motor operates smoothly. Next, reverse the polarity and check that the motor operates smoothly in the reverse direction. If the operation is abnormal, replace the motor.

Scheme 50

Scheme 51

1. Remove the rear door trim panel. Refer to REAR DOOR .
2. Disconnect the 2P connector from the motor.
3. Connect the motor terminals directly to battery voltage (12V) and check that the motor operates smoothly. Next, reverse the polarity and check that the motor operates smoothly in the reverse direction. If the operation is abnormal, replace the motor.

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

1. Disconnect the negative (-) battery terminal.
2. Remove the front door trim panel. Refer to FRONT DOOR .
3. Disconnect the connector from the switch.
4. Check for continuity between the terminals in each switch position according to the table. If the continuity condition is not normal, replace the switch.

Scheme 59

Scheme 60

Scheme 61

Scheme 62

1. Disconnect the negative (-) battery terminal.
2. Remove the front door trim panel. Refer to FRONT DOOR .
3. Disconnect the connector from the switch.
4. Check for continuity between the terminals in each switch position according to the table. If the continuity condition is not normal, replace the switch.

Scheme 63

Scheme 64

1. Disconnect the negative (-) battery terminal.
2. Remove the rear door trim panel. Refer to REAR DOOR .
3. Disconnect the 8P connector from the switch.
4. Check for continuity between the terminals in each switch position according to the table. If the continuity condition is not normal, replace the switch.

Scheme 65

Scheme 66

1. It will be able to diagnose defects of power window with GDS quickly. GDS can operates actuator forcefully, input/output value monitoring and self diagnosis.
2. Select model and "BCM".
3. Select the "SJB" to check.
4. Select "Current data", if you will check current data of power window system. It provides input/output status of SJB.
5. If you will check the power door lock operation forcefully, select "Actuation test".
