Operation Time Limiter

Maximal operation time of power window motor is limited to 15 sec (EEPROM programmable).

Scheme 20

Scheme 21

Scheme 22

Scheme 23

1. Remove the front door trim panel. (Refer to the " «FRONT DOOR»(ref-675084-S18044142972014120400000) ")
2. Disconnect the connector from the motor.
3. Connect the motor terminals No. 2 and No. 3 directly to battery voltage (12V) and check that the motor operates smoothly. If the operation is abnormal, replace the motor. [Safety Power Window]
4. Connect the motor terminals directly to battery voltage (12V) and check that the motor operates smoothly. Next, reverse the polarity and check that the motor operates smoothly in the reverse direction. If the operation is abnormal, replace the motor.

Scheme 24

Scheme 25

1. Remove the rear door trim panel. (Refer to the " «REAR DOOR»(ref-675084-S18251141812014120400000) ")
2. Disconnect the 2P connector from the motor.
3. Connect the motor terminals directly to battery voltage (12V) and check that the motor operates smoothly. Next, reverse the polarity and check that the motor operates smoothly in the reverse direction. If the operation is abnormal, replace the motor.

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

1. Disconnect the negative (-) battery terminal.
2. Remove the front door trim panel. (Refer to the " «FRONT DOOR»(ref-675084-S18044142972014120400000) ")
3. Disconnect the connector from the switch.
4. Check for continuity between the terminals in each switch position according to the table. If the continuity condition is not normal, replace the switch.

Scheme 34

Scheme 35

Scheme 36

Scheme 37

1. Disconnect the negative (-) battery terminal.
2. Remove the front door trim panel. (Refer to the " «FRONT DOOR»(ref-675084-S18044142972014120400000) ")
3. Disconnect the connector from the switch.
4. Check for continuity between the terminals in each switch position according to the table. If the continuity condition is not normal, replace the switch.

Scheme 38

Scheme 39

1. Disconnect the negative (-) battery terminal.
2. Remove the rear door trim panel. (Refer to the " «REAR DOOR»(ref-675084-S18251141812014120400000) ")
3. Disconnect the 8P connector from the switch.
4. Check for continuity between the terminals in each switch position according to the table. If the continuity condition is not normal, replace the switch.

Scheme 40

Scheme 41

1. It will be able to diagnose defects of power window with GDS quickly. GDS can operates actuator forcefully, input/output value monitoring and self diagnosis.
2. Select model and "BCM".
3. Select the "SJB" to check.
4. Select "Current data", if you will check current data of power window system. It provides input/output status of SJB.
5. If you will check the power door lock operation forcefully, select "Actuation test".
