Lighting Switch Inspection

With the multifunction switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the multi-function switch.

Scheme 21

Scheme 22

Scheme 23

Scheme 24

HU : Head lamp high beam

HL : Head lamp low beam

P : Head lamp passing switch

Scheme 25

Scheme 26

Wiper And Washer Switch Inspection

With the multifunction switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the multi-function switch.

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

1. Check BCM input/output specification of multifunction switch using the GDS. If the specification is abnormal, replace the lamp or wiper switch.
2. If diagnosis is required on the multifunction switch, select model and "BCM".
3. To consult the present input/output value of BCM, "Current DATA". It provides information of BCM input/output conditions of power supply, turn signal/brake lamp, headlamp, door, locks, outside mirror, wiper, auto-light and transmitters etc.
4. To perform compulsory operation on BCM input factors, select "ACTUATION TEST".

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

1. Disconnect the negative (-) battery terminal.
2. Remove the steering wheel. Refer to STEERING COLUMN & SHAFT .
3. Remove the steering column upper and lower shrouds after removing 3 screws.
4. If it is necessary to remove. The wiper & washer switch (A) only, release the lock of wiper switch using tool without removing the steering wheel and the clock spring.
5. Disconnect the lighting switch connector (A) and wiper & washer switch connector (B).
6. Remove the steering wheel. Refer to STEERING COLUMN & SHAFT .
7. Remove the clock spring. Refer to AIRBAG MODULE .
8. Remove the multifunction switch assembly (A) after loosening the mounting screws.
