Lighting Switch Inspection
With the multifunction switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the multi-function switch.
Scheme 3
Scheme 4
Scheme 5
Scheme 6
HU: Head lamp high beam
HL: Head lamp low beam
P: Head lamp passing switch
Scheme 7
Scheme 8
Wiper And Washer Switch Inspection
With the multifunction switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the multi-function switch.
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
- Check BCM input/output specification of multifunction switch using the GDS. If the specification is abnormal, replace the lamp or wiper switch.
- If diagnosis is required on the multifunction switch, select model and "BCM".
- To consult the present input/output value of BCM, "Current DATA". It provides information of BCM input/output conditions of power supply, turn signal/brake lamp, headlamp, door, locks, outside mirror, wiper, auto-light and transmitters etc.
- To perform compulsory operation on BCM input factors, select "ACTUATION TEST".
Scheme 14
Scheme 15
Scheme 16
Scheme 17
Scheme 18
- Disconnect the negative (-) battery terminal.
- Remove the steering wheel. (Refer to the " «STEERING COLUMN AND SHAFT»(ref-675062-S39430859222014120400000) ")
- Remove the steering column upper and lower shrouds after removing 3 screws.
- If it is necessary to remove. The wiper & washer switch (A) only, release the lock of wiper switch using tool without removing the steering wheel and the clock spring.
- Disconnect the lighting switch connector (A) and wiper & washer switch connector (B).
- Remove the steering wheel. (Refer to the " «STEERING COLUMN AND SHAFT»(ref-675062-S39430859222014120400000) ")
- Remove the clock spring. (Refer to the «DRIVER AIRBAG (DAB) MODULE AND CLOCK SPRING»(ref-675093-S30357001562014120400000) .
- Remove the multifunction switch assembly (A) after loosening the mounting screws.
