Seat Electrical - Optima Hev: Overview Kia Optima III рестайлинг

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

1. Disconnect the connectors for each motor. Front height motor Slide motor Rear height motor Recline motor Lumber support motor
2. With the battery connected directly to the motor terminals, check if the motors run smoothly.
3. Reverse the connections and check that the motor rotates in reverse.
4. If there is an abnormality, replace the motors.

Scheme 78

Scheme 79

1. Disconnect the limit switch and operate the limit switch.
2. Check for continuity between the terminals.
3. Make sure that the seat operation is normal in the reverse after the maximum operation.
4. If there is an abnormality, replace the limit switch.

Scheme 80

Scheme 81

Description

Using the blows power of FAN on seat, remove the moisture, sweat and warmth from occupants and surface of seats.

It inhales the indoor air through the blower installed at the seat cushion lower part, and supplies the air into the seat cushion and the seat back through the duct.

It sends a slight air throughout the seat surface through the air channel set up at seat cushion and seat back.

Note. Make sure not to spill drink or water on the seat when equipping with ventilation system seat Because of inhaling the slight air, it is difficult to feel the air strength by the sense of touch.

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

1. Remove the front seat assembly. (Refer to Body group - " «FRONT SEAT»(ref-675127-S03488356862014120400000) ")
2. Remove the seat back cover and cushion cover. (Refer to Body group - " «FRONT SEAT»(ref-675127-S03488356862014120400000) ")
3. Remove the ventilation duct (A) after loosening screws and removing fixing hook (B).
4. Remove the air ventilation panel (A) and fixing clip (B) from seat cushion.
5. Remove the climate blower and duct (A) after loosening the fixing clips and screws.
6. Remove the air ventilation control unit mounting screws.
7. Disconnect the connector and remove the air ventilation control unit. [Driver] [Passenger]
