Engine & Transaxle Assembly - 2.0L - Optima: Removal & Installation Kia Optima III рестайлинг

Mechanical 33 illustrations ~1050 words

Removal

CAUTIONUse fender covers to avoid damaging painted surfaces. To avoid damage, unplug the wiring connectors carefully while holding the connector portion.

Note. Mark all wiring and hoses to avoid misconnection. To release the fuel system pressure before removing the engine assembly, start the engine with the fuel pump relay removed. Turn off the ignition switch after engine stops.

Scheme 270

Scheme 270

Scheme 271

Scheme 271

Scheme 272

Scheme 272

Scheme 273

Scheme 273

Scheme 274

Scheme 274

Scheme 275

Scheme 275

Scheme 276

Scheme 276

Scheme 277

Scheme 277

Scheme 278

Scheme 278

Scheme 279

Scheme 279

Scheme 280

Scheme 280

Scheme 281

Scheme 281

Scheme 282

Scheme 282

Scheme 283

Scheme 283

Scheme 284

Scheme 284

Scheme 285

Scheme 285

Scheme 286

Scheme 286

Scheme 287

Scheme 287

Scheme 288

Scheme 288

Scheme 289

Scheme 289

Scheme 290

Scheme 290

Scheme 291

Scheme 291

Scheme 292

Scheme 292

Scheme 293

Scheme 293

Scheme 294

Scheme 294

Scheme 295

Scheme 295

Scheme 296

Scheme 296

Scheme 297

Scheme 297

Scheme 298

Scheme 298

Scheme 299

Scheme 299

Scheme 300

Scheme 300

Scheme 301

Scheme 301

Scheme 302

Scheme 302
  1. Remove the engine cover (A).
  2. Disconnect the battery terminals (A).
  3. Remove the air duct (B) after removing the mounting bolts. Tightening torque: (-) terminal : 7.8 ~ 9.8 N.m (0.8 ~ 1.0 kgf.m, 5.8 ~ 7.2 lb-ft) (+) terminal : 7.8 ~ 9.8 N.m (0.8 ~ 1.0 kgf.m, 5.8 ~ 7.2 lb-ft)
  4. Remove the battery (A) after removing the mounting bracket (B). Tightening torque: 8.8 ~ 13.7 N.m (0.9 ~ 1.4 kgf.m, 6.5 ~ 10.1 lb-ft)
  5. Remove the air cleaner assembly. Disconnect the breather hose (A), the recirculation hose (B) and the brake booster vacuum hose (C). Disconnect the air intake hose (D) and then remove the air cleaner assembly (E). Tightening torque Hose clamp bolt: 2.9 ~ 4.9 N.m (0.3 ~ 0.5kgf.m, 2.2 ~ 3.6 lb-ft) Air cleaner assembly bolts: 7.8 ~ 9.8 N.m (0.8 ~ 1.0kgf.m, 5.8 ~ 7.2 lb-ft)
  6. Remove the battery tray (A). Tightening torque: 8.8 ~ 13.7 N.m (0.9 ~ 1.4 kgf.m, 6.5 ~ 10.1 lb-ft)
  7. Remove the intercooler inlet hose (A). Tightening torque: 4.9 ~ 6.9 N.m (0.5 ~ 0.7 kgf.m, 3.6 ~ 5.1 lb-ft)
  8. Disconnect the recirculation valve connector (A) and the vacuum hose (B) and then remove the intercooler inlet pipe & hose assembly (C) Tightening torque Pipe mounting bolt: 14.7 ~ 19.6 N.m (1.5 ~ 2.0 kgf.m, 10.8 ~ 14.5 lb-ft)
  9. Disconnect the intercooler outlet hose clip (A).
  10. Disconnect the boost pressure sensor connector (A) and then remove the intercooler outlet pipe & hose assembly (B) after disconnecting the hose clamp (C). Tightening torque 4.9 ~ 6.9 N.m (0.5 ~ 0.7 kgf.m, 3.6 ~ 5.1 lb-ft)
  11. Remove the engine room under covers (A, B). Tightening torque: 9.8 ~ 11.8 N.m (1.0 ~ 1.2 kgf.m, 7.2 ~ 8.7 lb-ft) NOTE: When removing the under cover (B), unfasten the mounting bracket bolts and then remove the under cover and mounting bracket assembly.
  12. Loosen the drain plug, and drain the engine coolant. Remove the radiator cap to drain with speed. Refer to COOLING SYSTEM .
  13. Disconnect the radiator upper hose (A) and lower hose (B).
  14. Recover the refrigerant and then remove the high pressure pipe and low pressure pipe (A). Refer to AIR CONDITIONING SYSTEM .
  15. Disconnect the (+) cable (A) from the fuse/relay box and the front connector (B). Then remove the wiring protector (C).
  16. Disconnect the ECM connectors (A) from the ECM, the fuse box connector (B) from the fuse/relay box and the engine ground line. Then remove the control wiring harness (C).
  17. Remove the transaxle wire harness connectors (A) and control cable (B) from the transaxle. Refer to «REMOVAL»(ref-675191-S39109056842014120400000) .
  18. Disconnect the ATF cooler hoses (A).
  19. Disconnect the intensifier hose (A) and the vacuum hose (B).
  20. Disconnect the fuel hose (A) and PCSV (Purge control solenoid valve) hose (B).
  21. Disconnect the heater hoses (A).
  22. Remove the front muffler (B) after disconnecting the front oxygen sensor connector (A). Tightening torque: 39.2 ~ 58.8 N.m (4.0 ~ 6.0 kgf.m, 28.9 ~ 43.4 lb-ft)
  23. Remove the steering u-joint mounting bolt (A). Refer to STEERING COLUMN AND SHAFT .
  24. Remove the front wheels.
  25. Remove the lower arms (A). Refer to FRONT LOWER ARM .
  26. Remove the stabilizer bar links (A). Refer to FRONT STABILIZER BAR .
  27. Remove the tie rod ends (A). Refer to REPAIR PROCEDURES .
  28. Disconnect the drive shafts from the axle hubs. Refer to «FRONT DRIVESHAFT»(ref-675194-S01069303272014120400000) .
  29. Remove the roll rod bracket (A). Tightening torque: Nut (B) : 107.9 ~ 127.5 N.m (11.0 ~ 13.0 kgf.m, 79.6 ~ 94.0 lb-ft) Bolt (C) : 49.0 ~ 63.7 N.m (5.0 ~ 6.5 kgf.m, 36.2 ~ 47.0 lb-ft)
  30. Support the sub frame (A) with a floor jack, and then remove the sub frame mounting bolts and nuts. Tightening torque: Sub frame mounting bolts & nuts : 156.9 ~ 176.5 N.m (16.0 ~ 18.0 kgf.m, 115.7 ~ 130.2 lb-ft) Stay mounting bolts : 44.1 ~ 58.8 N.m (4.5 ~ 6.0 kgf.m, 32.5 ~ 43.4 lb-ft) NOTE: After removing the sub frame mounting bolt, the engine and transaxle assembly may fall downward, and so support them securely with floor jack. Verify that the hoses and connectors are disconnected before removing the engine and transaxle assembly.
  31. Disconnect the ground line (A), and then remove the engine mounting support bracket (B). Tightening torque: 88.3 ~ 107.9 N.m (9.0 ~ 11.0 kgf.m, 65.1 ~ 79.6 lb-ft)
  32. Disconnect the ground line (A).
  33. Remove the service cover (A).
  34. Remove the transaxle mounting fixing bolt (A). Tightening torque: 107.9 ~ 127.5 N.m (11.0 ~ 13.0 kgf.m, 79.6 ~ 94.0 lb-ft)
  35. Remove the engine and transaxle assembly by lifting vehicle. CAUTION: When remove the engine and transaxle assembly, be careful not to damage any surrounding parts or body components.

Installation

Installation is in the reverse order of removal.

Perform the following

  1. Adjust shift cable.
  2. Refill engine with engine oil.
  3. Refill a transaxle with fluid.
  4. Refill a radiator and a reservoir tank with engine coolant.
  5. Clean battery posts and cable terminals and assemble.
  6. Inspect for fuel leakage. After assemble the fuel line, turn on the ignition switch (do not operate the starter) so that the fuel pump runs for approximately two seconds and fuel line pressurizes. Repeat this operation two or three times, then check for fuel leakage at any point in the fuel line.
