Ignition System - 2.4L - Optima: Specifications Kia Optima III рестайлинг

Ignition System 4 illustrations

Specifications

ItemSpecification
Primary Coil Resistance (ohms)0.62 ± 10% [20°C (68°F)]
Secondary Coil Resistance (kohms)7.0 ± 15% [20°C (68°F)]

IGNITION COIL SPECIFICATIONS

Scheme 26

Scheme 26: Schematic Diagrams
Scheme 26: Schematic Diagrams

Scheme 27

Scheme 27: Removal
Scheme 27: Removal

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29
  1. Disconnect the battery negative terminal.
  2. Remove the engine cover.
  3. Disconnect the ignition coil connector (A). NOTE: When removing the ignition coil connector, pull the lock pin (A) and push the clip (B).
  4. Remove the ignition coil (A).
ItemSpecification
TypeFXU16HR11
Gap1.0 ~1.1 mm (0.0394 ~ 0.0433 in.)

SPARK PLUG SPECIFICATIONS
