Ignition System - 2.0L - Optima: Specifications Kia Optima III рестайлинг

Ignition System 4 illustrations

Specifications

ItemSpecification
Primary Coil Resistance (ohms)0.62 ± 10% [20°C (68°F)]
Secondary Coil Resistance (kohms)7.0 ± 15% [20°C (68°F)]

IGNITION COIL SPECIFICATIONS

Scheme 13

Scheme 13: Schematic Diagrams
Scheme 13: Schematic Diagrams

Scheme 14

Scheme 14: Removal
Scheme 14: Removal

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16
  1. Disconnect the battery negative terminal.
  2. Remove the engine cover.
  3. Disconnect the ignition coil connector (A). NOTE: When removing the ignition coil connector, pull the lock pin (A) and push the clip (B).
  4. Remove the ignition coil (A).
ItemSpecification
TypeZXU22HCR8
Gap0.7 ~ 0.8 mm (0.028 ~ 0.031 in.)

SPARK PLUG SPECIFICATIONS
