Multi Fuse
Multi Fuse is for optimizing the engine room package.
Scheme 41
Note. Multi fuse is needed to replace entirely when there is damage to only one fuse. When replace the multi fuse, refer to the "Engine compartment - COMPONENT LOCATION " diagram exactly. Use the multi fuse capacities for each circuit correctly. Remove the nut cover (A) when removing the nut.
Scheme 42
Circuit (I/P Junction Box)
| Fuse Name | (A) | Circuit Protected | |
|---|---|---|---|
| MULTI MEDIA | 15A | A/V Navigation Head Unit, Audio, MTS Module | |
| MEMORY 2 | 7.5A | RF Receiver | |
| CLUSTER | 10A | Instrument Cluster | |
| START | 7.5A | W/O Smart Key, Burglar Alarm Relay, W/Smart Key: Transaxle Range Switch, Smart Key Control Module, E/R Fuse & Relay Box (Start Relay) | |
| PDM 1 | 25A | Smart Key Control Module | |
| TRUNK | 10A | Trunk Relay, Fuel Filler Door & Trunk Lid Switch | |
| MDPS | 7.5A | MDPS Unit | |
| HTD STRG | 15A | Clock Spring | |
| MODULE 7 | 10A | Sport Mode Switch, Rear Power Window Switch LH/RH, Key Solenoid | |
| MODULE 2 | 10A | BCM, Driver IMS Module | |
| A/BAG IND | 10A | Instrument Cluster | |
| PDM 3 | 7.5A | Smart Key Control Module | |
| MODULE 5 | 7.5A | BCM, Smart Key Control Module | |
| PDM 2 | 10A | Smart Key Control Module, Start Stop Button Switch | |
| DR LOCK | 20A | Door Lock/Unlock Relay, Turn Signal Lamp Sound Relay | |
| BRAKE SWITCH | 10A | Smart Key Control Module, Stomp Lamp Switch | |
| MODULE 3 | 10A | Rear Parking Assist Sensor LH/RH, Rear Parking Assist Sensor LH/RH (CENTER), Blind Spot Detection Radar LH/RH, Stop Lamp Switch, Crash Pad Switch, Tire Pressure Monitoring Module, Rear Parking Assist Buzzer, Electro Chromic Mirror | |
| EPB | 10A | Electric Parking Brake module | |
| A/CON | 7.5A | A/C Control Module, E/R Fuse, & Relay Box (Blower Relay) | |
| P/SEAT (PASS) | 20A | Passenger Seat Manual Switch | |
| S/HEATER (RR) | 20A | Rear Seat Warmer (LH/RH) | |
| MEMORY 1 | 10A | Driver IMS Module, A/C Control Module, Instrument Cluster, BCM, Outside Mirror Auto Folding Relay, Outside Mirror Auto Unfolding Relay, Electro Chromic Mirror, Tire Pressure Monitoring Module, Auto Light & Photo Sensor, Data Link Connector | |
| MODULE 4 | 10A | Auto Head Lamp Leveling Device Module, Driver/Passenger CCS Control Module Driver/Passenger Seat Warmer Module, Rear Seat Warmer Module LH/RH, A/C Control Module, Multipurpose Check Connector, Head Lamp Leveling Device Actuator LH/RH, Front Seat Warmer & CCS Switch, ATM Lever Indicator, Electric Parking Brake Switch, A/V & Navigation Head Unit, MTS Module | |
| AMP | 30A | AMP | |
| P/WDW (RH) | 25A | P/WDW (RH)Relay, Passenger Power Window Safety Module | |
| SUNROOF | 20A | Panorama Sunroof | |
| A/BAG | 15A | SRS Control Module, Passenger Weight Classification Module | |
| IG 1 | 25A | E/R Fuse & Relay Box (Fuse: OPCU 2, AHB 3, ECU 4, TCU 2) | |
| WIPER | 25A | Malfunction Switch, Front Wiper Motor, E/R Fuse & Relay Box (Wiper Relay, Flash Sensor Relay) | |
| P/SEAT (DRV) | 30A | With IMS, Driver IMS Module, Driver Seat Manual Switch, W/O IMS: Driver Seat Manual Switch (10WAY), Driver Lumbar Support Switch (2WAY) | |
| P/WDW (LH) | 25A | P/WDW (LH) Relay, Driver Power Window Safety Module | |
| S/HEATER (FRT) SEAT VENT (FRT) | 20A | Driver/Passenger CCS Cushion Warmer, Driver/Passenger Seat Warmer Module | |
| INTERIOR LAMP | 10A | Driver/Passenger Smart Key Outside Handle, Trunk Room Lamp, Driver/Passenger Door Scuff Lamp, Overhead Console Lamp, Vanity Lamp LH/RH, Room Lamp, Rear Personal Lamp, Glove Box Lamp | |
| C/LIGHTER | 20A | Cigar Lighter | |
| POWER OUTLET | 20A | Front Power Outlet | |
| MODULE 6 | 7.5A | Rear Seat Warmer LH/RH, Panorama Sunroof, Rain Sensor, E/R Fuse & Relay Box (EWP Relay) | |
| MODULE 1 | 10A | A/C Control Module, BCM, Smart Key Control Module, Overhead Console Lamp, Crash Pad Mood Lamp, Audio, A/V Navigation Head Unit, AMP, Power/Passenger Door Mood Lamp, Power Outside Mirror Switch, Vess Limit, MTS Module | |
| HTD MIRROR | 10A | Driver/Passenger Power Outside Mirror, A/C Control Module | |
CIRCUIT INFORMATION (I/P JUNCTION BOX)
* USE THE DESIGNATED FUSE AND RELAY ONLY
