Scheme 1
Scheme 2
Scheme 3
| Fuse Name | (A) | Circuit Protected | |
|---|---|---|---|
| MULTI FUSE | MDPS | 80A | MDPS Unit |
| B+3 | 60A | Smart Junction Box (IPS 1, IPS 2, IPS 7, Fuse -S/HEATER (FRT), SEAT VENT (FRT), BRAKE SWITCH, SUNROOF, Leak Current Autocut Device) | |
| RR HTD | 40A | RR HTD Relay | |
| AHB 2 | 40A | Hydraulic Power Unit | |
| AHB 1 | 40A | Hydraulic Power Unit, Multipurpose Check Connector | |
| IG 2 | 40A | PDM 3 (IG2) Relay | |
| BLOWER | 40A | BLOWER Relay | |
| B+2 | 60A | Smart Junction Box (IPS 3, IPS 4, IPS 5, IPS 6, Fuse - P/SEAT (DRV), P/SEAT (PASS), AMP, PDM 2) | |
| WIPER | 10A | WIPER Relay, Rain Sensor, Front Wiper Motor, PCM | |
| OPCU 2 | 10A | Hybrid Fuse & Relay Box (OPCU Relay), Electric Oil Pump Unit | |
| OPCU 1 | 20A | Electric Oil Pump Unit | |
| INVERTER | 10A | MCU, Low Voltage DC-DC Converter | |
| TCU 1 | 20A | PCM | |
| STOP LAMP | 15A | Stop Signal Electronic Module | |
| DEICER | 20A | E/R Fuse & Relay Box (Deicer Relay) | |
| EWP | 10A | E/R Fuse & Relay Box (EWP Relay) | |
| IG 1 | 40A | E/R Fuse & Relay Box (PDM 1(ACC) Relay, PDM 2 (IG 1) Relay) | |
| B+1 | 50A | Smart Junction Box (Fuse - PDM 1, S/HEATER (RR), TRUNK, DR LOCK, P/WDW (LH), P/WDW (RH), MODULE 7) | |
| BATTERY C/FAN | 20A | BMS Blower Motor Relay | |
| HEV ECU | 20A | Hybrid Control Unit | |
| ECU 2 | 40A | EMS Box (HORN 15A, ECU 3 15A, ECU 1 30A, F/PUMP 20A) | |
| ECU 4 | 10A | PCM | |
| TCU 2 | 15A | E/R Fuse & Relay Box (PDM 1(ACC) Relay, PDM 2(IG 1) Relay) Transaxle Range Switch | |
| AHB 3 | 10A | Hydraulic Power Unit | |
| B/UP LAMP | 10A | BCM, A/V Navigation Head Unit, Audio, Electro Chromic Mirror, Rear Combination Lamp (IN) LH/RH, PCM, Transaxle Range Switch | |
CIRCUIT INFORMATION
* USE THE DESIGNATED FUSE AND RELAY ONLY.
Scheme 4
* USE THE DESIGNATED FUSE AND RELAY ONLY.
