Power Windows - Hev: Overview Kia Optima III

Scheme 41

Operation Time Limiter

Maximal operation time of power window motor is limited to 15 sec (EEPROM programmable).

Scheme 42

Scheme 43

Scheme 44

Scheme 45

1. Remove the front door trim panel. (Refer to the " «FRONT DOOR»(ref-535761-S36290281972013031200000) ")
2. Disconnect the connector from the motor.
3. Connect the motor terminals No. 2 and No. 3 directly to battery voltage (12V) and check that the motor operates smoothly. If the operation is abnormal, replace the motor. [Safety Power Window]
4. Connect the motor terminals directly to battery voltage (12V) and check that the motor operates smoothly. Next, reverse the polarity and check that the motor operates smoothly in the reverse direction. If the operation is abnormal, replace the motor.

Scheme 46

Scheme 47

1. Remove the rear door trim panel. (Refer to the " «REAR DOOR»(ref-535761-S21134600252013031200000) ")
2. Disconnect the 2P connector from the motor.
3. Connect the motor terminals directly to battery voltage (12V) and check that the motor operates smoothly. Next, reverse the polarity and check that the motor operates smoothly in the reverse direction. If the operation is abnormal, replace the motor.

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

1. Disconnect the negative (-) battery terminal.
2. Remove the front door trim panel. (Refer to the " «FRONT DOOR»(ref-535761-S36290281972013031200000) ")
3. Disconnect the connector from the switch.
4. Check for continuity between the terminals in each switch position according to the table. If the continuity condition is not normal, replace the switch.

Scheme 56

Scheme 57

Scheme 58

1. Disconnect the negative (-) battery terminal.
2. Remove the front door trim panel. (Refer to the " «FRONT DOOR»(ref-535761-S36290281972013031200000) ")
3. Disconnect the connector from the switch.
4. Check for continuity between the terminals in each switch position according to the table. If the continuity condition is not normal, replace the switch.

Scheme 59

Scheme 60

Scheme 61

Scheme 62

1. Disconnect the negative (-) battery terminal.
2. Remove the rear door trim panel. (Refer to the " «REAR DOOR»(ref-535761-S21134600252013031200000) ")
3. Disconnect the 8P connector from the switch.
4. Check for continuity between the terminals in each switch position according to the table. If the continuity condition is not normal, replace the switch.

Scheme 63

Scheme 64

1. It will be able to diagnose defects of power window with GDS quickly. GDS can operates actuator forcefully, input/output value monitoring and self diagnosis.
2. Select model and "BCM".
3. Select the "SJB" to check.
4. Select "Current data", if you will check current data of power window system. It provides input/output status of SJB.
5. If you will check the power door lock operation forcefully, select "Actuation test".
