Power Windows - Except Hev: Overview Kia Optima III

Scheme 1

Operation Time Limiter

Maximal operation time of power window motor is limited to 15 sec (EEPROM programmable).

Scheme 2

Scheme 3

1. Remove the front door trim panel. Refer to «FRONT DOOR»(ref-429575-S06879073872011101500000) .
2. Disconnect the connector from the motor.
3. Connect the motor terminals No. 2 and No. 3 directly to battery voltage (12V) and check that the motor operates smoothly. If the operation is abnormal, replace the motor.

Scheme 4

Scheme 5

1. 4. Connect the motor terminals directly to battery voltage (12V) and check that the motor operates smoothly. Next, reverse the polarity and check that the motor operates smoothly in the reverse direction. If the operation is abnormal, replace the motor.

Scheme 6

Scheme 7

1. Remove the rear door trim panel. Refer to «REAR DOOR»(ref-429575-S24740005352011101500000) .
2. Disconnect the 2P connector from the motor.
3. Connect the motor terminals directly to battery voltage (12V) and check that the motor operates smoothly. Next, reverse the polarity and check that the motor operates smoothly in the reverse direction. If the operation is abnormal, replace the motor.

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

1. Disconnect the negative (-) battery terminal.
2. Remove the front door trim panel. Refer to «FRONT DOOR»(ref-429575-S06879073872011101500000) .
3. Disconnect the connector from the switch.
4. Check for continuity between the terminals in each switch position according to the table. If the continuity condition is not normal, replace the switch.

Scheme 15

Scheme 16

Scheme 17

Scheme 18

1. Disconnect the negative (-) battery terminal.
2. Remove the front door trim panel. Refer to «FRONT DOOR»(ref-429575-S06879073872011101500000) .
3. Disconnect the connector from the switch.
4. Check for continuity between the terminals in each switch position according to the table. If the continuity condition is not normal, replace the switch.

Scheme 19

Scheme 20

1. Disconnect the negative (-) battery terminal.
2. Remove the rear door trim panel. Refer to «REAR DOOR»(ref-429575-S24740005352011101500000) .
3. Disconnect the 8P connector from the switch.
4. Check for continuity between the terminals in each switch position according to the table. If the continuity condition is not normal, replace the switch.

Scheme 21

Scheme 22

1. It will be able to diagnose defects of power window with GDS quickly. GDS can operates actuator forcefully, input/output value monitoring and self diagnosis.
2. Select model and "BCM".
3. Select the "SJB" to check.
4. Select "Current data", if you will check current data of power window system. It provides input/output status of SJB.
5. If you will check the power door lock operation forcefully, select "Actuation test".
