Fuses & Relays - Hev: Other Kia Optima III

Fuses & Circuit Breakers 24 illustrations ~310 words

Network Configuration

The Network of the SJB(Smart Junction Box) consists of Low speed CAN as shown in the following figure.

Scheme 58

Scheme 58: Network Configuration
Scheme 58: Network Configuration
ECMEngine Control Module
HCUHybrid Control Module
MCUMotor Control Module
BMSBattery Management System
TCMTransaxle Control Module
EBSElectronic Brake System
OPUOil Pump Unit
MDPSMotor Driving Power Steering
LDCLow DC/DC Converter
FATCFull Automatic Temperature Control
EWPElectronic Water Pump
AAFActive Air Flap
BCMBody Control Module
SMKSmart Key unit
PDMPower Distribution Module
DDMDriver Door Module
ADMAssist Door Module
SCMSteering Control Module
PSMPower Seat Module

Termination Resistor

The cluster has CAN termination resistor. It is possible that CAN termination resistor value is changed by number of CAN controller. The termination resistor value of the cluster is 510 ohms.

Function Requirements

The BCM controls IPS and relay on the SJB. For example, if BCM requests head lamp low beam control, then BCM requests related lamp control at one time.

Signal Flow Diagram

This chapter defines signal between SJB and peripheral electrical apparatus in the form of signal flow diagram. Control of the IPS and relay is required by BCM. Following figure expresses power source that is operating power condition

NoSwitch Input
1IGN1
2IGN2
3Driver S/Beltelt switch
4Assist S/Beltelt switch
5Driver door unlock switch
6Assist door unlock switch
7RL door unlock switch
8RR door unlock switch
9Driver door switch
10Assist door switch
11RL door switch
12RR door switch
13Driver&Assist door key lock
14Driver door key unlock
15Assist door key unlock
16Hood switch
17P/W Driver lock switch
18P/W Driver unlock switch
19T/signal LH switch
20T/signal RH switch
21Hazard switch
22Trunk switch
23Trunk release switch
24Trunk lid HDL switch
25Brake fluid sensor
26Parking brake switch
27Multi function switch
28Inhibit 'R'
29CANADA DRL GND
30HID option
31RHD option

INPUT SIGNAL

NoRelay Control
1B/Alarm relay
2B/Horn relay
3RR HTD relay
4Driver door unlock relay
5Deicer relay
6Trunk lid relay
7Rear window main relay
8Sound relay
9Door lock relay
10Door unlock relay

OUTPUT SIGNAL

NoIPS Control
1H/Lamp HI LH
2H/Lamp HI RH
3H/Lamp LO LH
4H/Lamp LO RH
5Front fog LP LH/RH
6External Tail lamp LH
7External Tail lamp RH
8T/signal LP FL
9T/signal LP FR
10T/signal LP RL
11T/signal LP RR
12INT Tail lamp LP
13S/Belt LP LH
14S/Belt LP RH
15DRL

Scheme 59

Scheme 59: Door Switch Input
Scheme 59: Door Switch Input

Scheme 60

Scheme 60: Door Lock Switch Input
Scheme 60: Door Lock Switch Input

Scheme 61

Scheme 61: Door Unlock Status Input
Scheme 61: Door Unlock Status Input

Scheme 62

Scheme 62: P/WDW DR Lock/Unlock Input
Scheme 62: P/WDW DR Lock/Unlock Input

Scheme 63

Scheme 63: Brake Switch Input
Scheme 63: Brake Switch Input

Scheme 64

Scheme 64: Seat Belt Switch Input
Scheme 64: Seat Belt Switch Input

Scheme 65

Scheme 65: Trunk Switch Input
Scheme 65: Trunk Switch Input

Scheme 66

Scheme 66: Hood Open Switch Input
Scheme 66: Hood Open Switch Input

Scheme 67

Scheme 67: CANADA DRL Option
Scheme 67: CANADA DRL Option

Scheme 68

Scheme 68: INHIBIT 'R' Input
Scheme 68: INHIBIT 'R' Input

Scheme 69

Scheme 69: Burglar Alarm Start Relay
Scheme 69: Burglar Alarm Start Relay

Scheme 70

Scheme 70: Burglar Alarm Horn Relay
Scheme 70: Burglar Alarm Horn Relay

Scheme 71

Scheme 71: Door Lock/Unlock Relay
Scheme 71: Door Lock/Unlock Relay

Scheme 72

Scheme 72: Trunk LID Release Relay Output
Scheme 72: Trunk LID Release Relay Output

Scheme 73

Scheme 73: Power Window Relay Output
Scheme 73: Power Window Relay Output

Scheme 74

Scheme 74: Defogger & Front Deicer Relay
Scheme 74: Defogger & Front Deicer Relay

Scheme 75

Scheme 75: Head Lamp Control
Scheme 75: Head Lamp Control

Scheme 76

Scheme 76: IPS Lamp Control
Scheme 76: IPS Lamp Control

Scheme 77

Scheme 77: Hazard & Turn Signal
Scheme 77: Hazard & Turn Signal

Power Relay (Type D)

Check for continuity between the terminals.

Scheme 78

Scheme 78: Power Relay (Type D)
Scheme 78: Power Relay (Type D)

Scheme 79

Scheme 79
Scheme 79
  1. C/Fan (hi) relay
  2. OPCU relay There should be continuity between the No. 30 and No. 87 terminals when power and ground are connected to the No. 85 and No. 86 terminals. There should be no continuity between the No. 30 and No. 87 terminals when power is disconnected.

Multi Fuse

Multi Fuse is for optimizing the engine room package.

Scheme 80

Scheme 80: Multi Fuse
Scheme 80: Multi Fuse

Note. Multi fuse is needed to replace entirely when there is damage to only one fuse. When replace the multi fuse, refer to the " COMPONENT LOCATION " diagram exactly. Use the multi fuse capacities for each circuit correctly. Remove the nut cover (A) when removing the nut.

Scheme 81

Scheme 81: Components
Scheme 81: Components
Fuse Name(A)Circuit Protected
MODULE 37.5ASport Mode Switch, Natural Vacuum Leak Detection
PDM 125ASmart Key Control Module
POWER OUTLET15AFront Power Outlet
MODULE 57.5ASmart Key Control Module, Rear Seat Warmer Relay LH/RH, Active Air Flap
MODULE 27.5ABCM, Panorama Sunroof, Rain Sensor
TRUNK10AI/P Junction Box (Trunk Lid Relay). Fuel Filter Door & Trunk Lid Switch, Trunk Room Lamp
CLOCK10AA/V & Navigation Head Unit, Audio, Smart Key Control Module, Overhead Console Lamp, Crash Pad Mood Lamp, VESS Unit, A/C Control Module, BCM, AMP, Power Outside Mirror Switch, Driver/Passenger Door Mood Lamp
C/LIGHTER15ACigarette Lighter
HTD STRG15ASteering Wheel Heater
A/CON7.5AA/C Control Module, E/R Fuse & Relay Box (Blower Relay, Water Pump Relay), Electronic A/C Compressor
WIPER25AMultifunction Switch, Front Wiper Motor, E/R Fuse & Relay Box (Wiper Relay, Ran SNSR Relay)
S/HEATER FRT20ADriver/passenger CCS Cushion Warmer, Driver/Passenger Seat Warmer Module
WATER PUMP HEV10AHybrid Water Pump
HTD MIRR10ADriver/Passenger, Power Outside Mirror
MODULE 4 HEV7.5AMCU, Hydraulic Power Unit, Low Voltage DC-DC Converter, LBMS Control Module
A/BAG IND7.5AInstrument Cluster (Air Bag IND.)
START7.5ATransaxle Range Switch, Hybrid Control Unit
S/HEATER RR15ARear Seat Warmer Relay LH/RH
P/SEAT PASS20APassenger Seat Manual Switch
MODULE 17.5AHead Lamp Leveling device Actuator LH/RH, Auto Head Lamp Leveling Device Module, Driver IMS Module, ATM Lever Indicator, BCM, Front Seat Warmer & CCS Switch, Driver/Passenger CCS Control Module, Driver/Passenger Seat Warmer Module, Audio, A/C Control Module, Electro Chromic Mirror, Lane Keeping Assist Module, Instrument Cluster
HCU20AHybrid Control Unit
A/BAG15ATelltale Lamp, SRS Control Module, Passenger Weight Classification Sensor
P/WDW LH25AI/P Junction Box (Power Window LH Relay), Driver Power Window Safety Module
AMP30AAMP
PDM 27.5AStart Stop Button Switch, Smart Key Control Module, Fob Holder, Stop Lamp Switch
BMS10ABMS Control Module
MDPS10AEPS Control Module, Crash Pad Switch, Tire Pressure Monitoring Module
PDM 37.5ASmart Key Control Module
P/WDW RH25AI/P Junction Box (Power Window RH Relay), Passenger Power Window Safety Module
P/SEAT DRV30ADriver IMS Module, Driver Seat Manual Switch, Driver Lumbar Support Switch
DR LOCK20ATwo Turn Unlock Relay, I/P Junction Box (Door Lock Relay, Door Unlock Relay, Turn Signal Lamp Sound Relay)
SUNROOF20APanorama Sunroof
IG 120AE/R Fuse & Relay Box (Fuse: ESC 3 10A, TCU 2 15A, ECU 4 10A, OPCU 2 10A)
POWER CONNECTORAUDIO15AA/V &Navigation Head Unit, Audio
ROOM LP10ADriver/Passenger Smart Key Outside Handle, Driver IMS Module, Lamp Auto Cut Relay, Driver/Passenger Door Scuff Lamp, A/C Control Module, Data Link Connector, RF Receiver, BCM, Electro Chromic Mirror, Instrument Cluster, Auto Light & Photo Sensor, Tire Pressure Monitoring Module

CIRCUIT INFORMATION (I/P JUNCTION BOX)

USE THE DESIGNATED FUSE AND RELAY ONLY
