Removal
Note. Take care not to scratch the center fascia panel and related parts. Eject all the disc before removing the audio unit to prevent damaging the CD player's load mechanism.
Scheme 163
Scheme 164
Scheme 165
Scheme 166
Scheme 167
Scheme 168
Scheme 169
Scheme 170
Scheme 171
Scheme 172
Scheme 173
Scheme 174
Scheme 175
- Disconnect the negative (-) battery terminal.
- Using a screwdriver or remover, remove the crash pad garnish RH (A). NOTE: Apply the protective tapes to crash pad garnish and its related parts.
- Using a screwdriver or remover, remove the crash pad side cover (A).
- After loosening the crash pad lower panel mounting screws, then remove the lower panel (A).
- Remove the switch connector (A) and SSB connector (B) from crash pad lower panel.
- Remove the crash pad garnish LH (A) after removing the screws.
- Remove the instrument cluster fascia panel (A) after loosening the screws.
- Remove the center fascia lower panel (A) after loosening the screws.
- Remove the connectors (A) and hose (B).
- Remove the center fascia upper panel (A) after loosening the screws.
- Remove the audio assembly (A) after loosening the mounting screws.
- Disconnect the audio connectors and cable (A), then remove the audio unit completely. NOTE: Lift the connector locking clip to the arrow direction, disconnect the connector. When assembling, install the connector and connector locking clip tightly. NOTE: If the CD does not eject, do not attempt to remove it because the audio unit may be damaged. Contact an authorized dealership for assistance.
Installation
- Connect the audio unit connectors and cables.
- Install the audio unit.
- Install the center fascia upper panel.
- Install the heater control unit.
- Install the crash pad garnish LH and instrument cluster fascia panel.
- Install the crash pad lower panel and side cover.
- Install the crash pad garnish RH.
Note. Make sure the audio head unit connectors are plugged in properly and the antenna cable is connected properly.
Scheme 176
Scheme 177
- Troubleshooting for Speaker Basic inspection of speaker Inspect the sound from speaker after verifying that the speaker mounting screws are removed and the wiring connector is connected to remove any possible vibration transmitted from body trims and surrounding parts. Case Troubleshooting No. Case Inspection/Remedy 1 Trembling sound Before replacing the speaker, inspect that the mounting screw is installed normally. After re-installing the speaker, verify that no trembling sound is heard. When hearing a trembling sound again, replace the speaker with new one. 2 Noise Check if the wiring connector is connected normally. If not, reconnect the wiring connector. In case of radio static, check if there is a noise from CD. If a noise is heard with the radio and CD on, replace the speaker with new one. NOTE: In case there is only radio static, this causes from poor radio reception. Thus the speaker needs no repair and replacement. 3 Speaker in operative Inspection of the wiring connection between the battery and the speaker Before replacing the speaker, inspect the wiring connection between the battery and the speaker is normal. Check the supply power to the speaker and the resistance, then inspect the sound quality. • Specified impedance: 2 ~ 4ohms (Scheme 177): Checking Wiring Connection Between Battery And Speaker If the speaker works poorly, replace it with new one. CAUTION: When handling the speakers: Do not damage the speaker with impact, like dropping or throwing it. Be careful not to drop water and oil on the speakers. Caution during handling of speaker because the material of diaphragm is paper which is easily torn by impact or external force. Modifying the audio system may cause damage the speakers. If this is the case, the speakers are not covered by the manufacturer's warranty.
- Reassemble the steering wheel remote control switch after connecting the connector.
- Reassemble the steering wheel.
- Reassemble the driver airbag module.
Note. Make sure the audio remote control switch and the airbag module connectors are plugged in properly.
Scheme 178
Scheme 179
- Install the multimedia jack.
- Connect the multimedia jack connector.
- Install the console upper cover.
- Install the shift lever knob.
Note. Make sure the multimedia connector and the console upper cover connectors are plugged in properly.
Scheme 180
There are several areas where a problem can occur: wiring harness, the radio, the CD player, and speaker. Troubleshooting enables you to confine the problem to a particular area.
