Audio System - Except Hev: Other Kia Optima III

Entertainment Systems 27 illustrations ~706 words

Speaker

ItemPA710SBA900BA900, BA950 (Infinity sound)
Input power (W or V)FrontMAX 40WMAX 50W
RearMAX 40WMAX 50W
MidrangeMAX 40WMAX 50W
Sub woofer16 V rms
CenterMAX 50W
Impedance (ohms)Front4.0 ± 0.62.0 ± 0.3
Rear4.0 ± 0.62.0 ± 0.3
Midrange4.0 ± 0.61.9 ± 0.3
Sub woofer4.8 ± 1.0
Center2.0 ± 0.3
Number of speaker68

ITEM SPECIFICATION CHART

Scheme 80

Scheme 80: Component Location
Scheme 80: Component Location

Scheme 81

Scheme 81: Components
Scheme 81: Components

Scheme 82

Scheme 82
Scheme 82

Scheme 83

Scheme 83
Scheme 83

Scheme 84

Scheme 84
Scheme 84

Scheme 85

Scheme 85
Scheme 85

Front Speaker

  1. Install the front speaker.
  2. Install the front door trim.

Rear Speaker

  1. Install the rear speaker.
  2. Install the rear door trim.

Crash Pad Midrange Speaker

  1. Install the midrange speaker.
  2. Install the speaker grille.

Subwoofer Speaker

  1. Install the subwoofer speaker after connecting the connector.
  2. Install the rear package tray and rear seat assembly.

External Amp

  1. Install the external amplifier after connecting the connector.
  2. Install the trunk right luggage side trim. NOTE: Make sure the speaker and related connectors are plugged in properly.

Center Speaker

  1. Install the center speaker.
  2. Install the center speaker grill.

Scheme 86

Scheme 86: Glass Antenna Test
Scheme 86: Glass Antenna Test

Scheme 87

Scheme 87
Scheme 87
  1. Wrap aluminum foil (A) around the tip of the tester probe (B) as shown.
  2. Touch one tester probe to the glass antenna terminal (A) and move the other tester probe along the antenna wires to check that continuity exists.

Glass Antenna Repair

Note. To make an effective repair, the broken section must be no longer than one inch.

Scheme 88

Scheme 88: Glass Antenna Repair
Scheme 88: Glass Antenna Repair

Scheme 89

Scheme 89
Scheme 89
  1. Lightly rub the area around the broken section (A) with fine steel wool, and then clean it with alcohol.
  2. Carefully mask above and below the broken portion of the glass antenna wire (B) with cellophane tape (C).
  3. Using a small brush, apply a heavy coat of silver conductive paint (A) extending about 1/8" on both sides of the break. Allow 30 minutes to dry. NOTE: Thoroughly mix the paint before use.
  4. Check for continuity in the repaired wire.
  5. Apply a second coat of paint in the same way. Let it dry three hours before removing the tape.

Scheme 90

Scheme 90: Glass Antenna Circuit Inspection
Scheme 90: Glass Antenna Circuit Inspection

Scheme 91

Scheme 91
Scheme 91

Scheme 92

Scheme 92
Scheme 92
  1. Remove the right side rear quarter trim. Then disconnect the antenna feeder cable (A) from the glass antenna amp.
  2. Turn the radio ON. Measure the voltage between the harness side feeder cable (A) and body ground (B). OK : approximately 12V (ACC+)
  3. Check for FM wire resistance between terminals of No. 1 and 3 FM antenna grid terminal AM antenna grid terminal Body ground. Standard value : 80~120Kohms Short : Approx. 0ohms Open : infinity ohms
  4. Check for AM wire resistance between terminals of No. 2 and 3. Standard value : 120~170Kohms Short : Approx. 0ohms Open : infinity ohms
  5. Check the grid lines for continuity.
  6. When a poor radio reception is not repaired through the above inspection methods, replace the amp. If the radio reception is still poor, check the radio cable for short and radio head unit for failure.

Scheme 93

Scheme 93: Antenna Cable
Scheme 93: Antenna Cable

Scheme 94

Scheme 94
Scheme 94

Scheme 95

Scheme 95
Scheme 95

Scheme 96

Scheme 96
Scheme 96
  1. Remove the antenna jack (A) from the audio unit and antenna.
  2. Check for continuity between the center poles of antenna cable.
  3. Check for continuity between the outer poles of antenna cable. There should be continuity.
  4. If there is no continuity, replace the antenna cable.
  5. Check for continuity between the center pole (A) and outer pole (B) of antenna cable. There should be no continuity.
  6. If there is continuity, replace the antenna cable.

Scheme 97

Scheme 97: Circuit Diagram
Scheme 97: Circuit Diagram

Scheme 98

Scheme 98
Scheme 98

Scheme 99

Scheme 99
Scheme 99

Scheme 100

Scheme 100: Inspection
Scheme 100: Inspection

Scheme 101

Scheme 101
Scheme 101
  1. Check the audio remote control switch (A) for resistance between connector terminals in each switch position. LH-Audio LH-Mute Audio CONNECTOR TERMINALS RESISTANCE SPECIFICATIONS CHART Switch Connector terminal Resistance (±5%) Volume down 2-7 6.81 kohms Volume up 2-7 4.61 kohms Mode 2-7 2.11 kohms Seek up 2-7 1.11 kohms Seek down 2-7 430 ohms Bluetooth + Voice CONNECTOR TERMINALS RESISTANCE SPECIFICATIONS CHART Switch Connector terminal Resistance (±5%) Bluetooth off 2-5 12.1 kohms Bluetooth on 2-5 34.1 kohms Voice 2-5 3.9 kohms Mute + Trip + Reset CONNECTOR TERMINALS RESISTANCE SPECIFICATIONS CHART Switch Connector terminal Resistance (±5%) Mute 3-4 0 ohms Trip (General option) 2-5 2.55 kohms Reset (General option) 2-5 5.55 kohms Trip (Cruise option) 2-5 1.1 kohms Reset (Cruise option) 2-5 4.1 kohms

Scheme 102

Scheme 102: Removal
Scheme 102: Removal

Scheme 103

Scheme 103
Scheme 103

Scheme 104

Scheme 104
Scheme 104

Scheme 105

Scheme 105
Scheme 105

Scheme 106

Scheme 106
Scheme 106
  1. Disconnect the negative (-) battery terminal.
  2. Remove the driver airbag module. Refer to «DRIVER AIRBAG (DAB) MODULE AND CLOCK SPRING»(ref-429545-S40143402252011101500000) .
  3. Remove the steering wheel. Refer to «STEERING COLUMN & SHAFT»(ref-429546-S03884827802011101500000) .
  4. Remove the steering wheel cover (A) after loosening the screws.
  5. Remove the steering wheel remote control switch connector (A) after loosening the mounting screws. LH-Audio LH-Mute
