Installation
- Install the wiper switch.
- Install the steering column upper and lower shrouds.
Scheme 20
Scheme 21
- Remove the windshield wiper arm and blade after removing a nut (A). Torque : 23~27 Nm (2.3~2.7 kgf.m, 16.9~19.9 lbf.ft)
- Remove the weather strip then remove the cowl top cover (A) after removing 4 clips (B).
- Remove the windshield wiper motor and linkage assembly after removing 2 bolts. Disconnect the wiper motor connector (A) and windshield deicer connector (B) from the wiper motor & linkage assembly.
Torque : 7-11Nm (0.7-1.1, kgf.m, 5.0-7.9 lbf.ft)
Scheme 22
Scheme 23
Scheme 24
- Install the wiper arm and blade to the specified position. WIPER ARM AND BLADE SPECIFIED POSITION CHART Specified position A B Distance [in (mm)] 1.26+0.2/0 (32+5/0) 1.26+0.2/0 (32+5/0)
- Set the washer nozzle on the specified spray position. WASHER NOZZLE SPECIFIED SPRAY POSITION CHART Specified position Distance [in (mm)] A 14.6 (370) B 21.2 (540) C 3.9 (100) D 17.5 (445) E 9.4 (240) F 3.5 (90) G 10.4 (265) H 12.6 (320) I 2.7 (70) J 15.9 (405) K 10.0 (255) L 19.9 (505)
- Install the washer reservoir.
- Install the washer hose and washer motor connector.
- Install the wheel guide and tires.
- Install the wire harness on the front washer reservoir.
Removal
| CAUTION | The rain sensor may not operate properly if contaminated. Protect the rain sensor surface by not removing the cover until installation time. The coupling pad on the rain sensor surface has adhesive strength. Take care when installing the sensor. If the sensor is separated from the windshield by force, the sensor or windshield may be damaged. Take care when removing the sensor. |
Scheme 25
- Remove the rain sensor cover first. Be careful not to damage the cover latch by applying excessive force. To remove the latch, pull aside the latch using the cover hole (B) with the little (-) screwdriver (A).
- Remove the wiring harness connector from sensor.
- Rain sensor module is attached to the front windshield by glue replacing the front windshield, remove the rain sensor module from the existing front windshield and install on the new front windshield.
Note. In case of the windshield with reflection layer which reflects the infrared rays in sensing field, remove the reflection layer from the rain sensor mounting position prior to installation. Avoid contamination of the sensor during installation.
Scheme 26
- Install the rainsensor bracket to the windshield glass using the tape. CAUTION: It is very important that the coupling pad pushes against the windshield completely to prevent bubbles from forming at the contact surface.
- Connect the rainsensor connector, and then install the sensor cover.
Scheme 27
- Wiper low and wiper high do not work.
- When washer switch is on, wiper does not work.
