Windshield Wiper/washer: Overview Kia Optima II рестайлинг

Scheme 1

Speed Operation Check

1. Remove the connector from the wiper motor.
2. Attach the positive (+) lead from the battery to terminal 6 and the negative (-) lead to terminal 5.
3. Check that the motor operates at low speed.
4. Connect the positive (+) lead from the battery to terminal 4 and the negative (-) lead to terminal 5.
5. Check that the motor operates at high speed.

Scheme 2

Automatic Stop Operation Check

1. Operate the motor at low speed using the stalk control.
2. Stop the motor operation anywhere except at the off position by disconnecting terminal 6.
3. Connect terminals 3 and 6.
4. Connect the positive (+) lead from the battery to terminal 2 and the negative (-) lead to terminal 5.
5. Check that the motor stops running at the off position.

Scheme 3

Scheme 4

1. Disconnect the negative (-) battery terminal.
2. Remove the wire harness on the front washer reservoir.
3. Remove the tires.
4. Remove the wheel guide.
5. Remove the washer hose and the washer motor connector.
6. Remove the washer reservoir (A) after removing 2 bolts.

Scheme 5

Description

The Rain sensing windshield wiper system is a wiper system that, in addition to providing normal wiper functions off, mist, manual low speed, manual high speed, and wash, provides automatic control of automatic intermittent automatic low, and automatic high speeds.

When the ignition key is in the ON position, the rain sensor will be activated.

Scheme 6

Operation Control

Wiper ECU transmits the signal as a rainsesor, and then the rainsensor perceives the rainwater to transmit to the wiping order wiper ECU, wiper ECU controls the wiper motor according to the signal.

Operation Condition

In case that engine starts under wiper switch AUTO, rainsensor activates after once wiper operation to inform the driver that the system is under AUTO.

Note. In case that the rainsensor doesn't work or malfunction, it is needed manual wiper switch operation by the driver.
